7 Pin NEMA Socket 200W LED Street Light with Dali Dimmable Function
HANGZHOU ZGSM TECHNOLOGY CO., LTD.- Power Supply：AC
- Color Temperature：3000K 4000K 5000K 5700K
- Lamp Body Material：Aluminum Alloy
- Power：60W
- Application：Highway, Outdoor Parking Lot
- IP Rating：IP66
Base Info
- Model NO.：ZGSM-LD200KL
- Certification：CE, EMC, FCC, LVD, RoHS, ENEC, Lm-79, Lm-80
- Input Voltage：100-240V,277V, 50,60Hz
- With Light Source：With Light Source
- LED Chips Brand：Lumileds 3030 2D or 5050
- Light Source：LED Light
- Lens：Glass
- CRI：>70
- Working Lifetime(Hour)：100000 Hours
- Transport Package：Export Cartons
- Specification：EN60598, CE, IEC
- Trademark：ZGSM
- Origin：China
- HS Code：940540900
- Production Capacity：500, 000 PCS,Month
Description
Basic Info.
Model NO. ZGSM-LD200KL Certification CE, EMC, FCC, LVD, RoHS, ENEC, Lm-79, Lm-80 Input Voltage 100-240V/277V, 50/60Hz With Light Source With Light Source LED Chips Brand Lumileds 3030 2D or 5050 Light Source LED Light Lens Glass CRI >70 Working Lifetime(Hour) 100000 Hours Transport Package Export Cartons Specification EN60598, CE, IEC Trademark ZGSM Origin China HS Code 940540900 Production Capacity 500, 000 PCS/MonthProduct Description
| Series No | Series K |
| Power | 25W, 35W, 55W, 60W, 90W,120W, 150W, 180W, 200W |
| Efficacy | 125-150lm/W |
| Input Voltage | 100-240/277 VAC, 50 / 60 Hz |
| Power Factor | >0.95 |
| Surge Protection | 10KV (Default) / 20KV (available on request) |
| IP Rating | IP66 |
| IK Rating | IK08 |
| CCT | 3000K, 4000K, 5000K, 5700K |
| CRI | Ra>70 (Default) / Ra>80 |
| Operating Temperature | -40°C to + 50°C |
| Beam Angle | Type I, Medium; Type II, Medium; Type III, Medium; |
| Mounting Option | Side entry or Vertical pole mounted |
| Warrantys | 5 Years |
| Certification | ENEC, CE, CB, ROHS, LM79, LM80, LM82, LM84, TM-21, ISTMT, IEC62471/62788 |
| Control | Photocell, DALI Dimmable, NEMA / Zhaga Socket, Motion Sensor, 1-10V Dimmable, Zigbee or LORA control |
