• Model NO.：ZGSM-LD100H
• Certification：CB, DLC, CE, CQC, EMC, LVD, RoHS, SAA, UL, Ce, EMC, LVD, RoHS, SAA, Saso
• Input Voltage：24v
• With Light Source：With Light Source
• Guarantee：3 Years
• Heat Radiator：Anodized Aluminum
• Nominal Wattage：100W
• Lifetime：50, 000h
• Power Factor(PF)：> 0.95
• Operating Voltage：100-240V AC, 50,60Hz or 24V DC
• Rating：IP66
• LED Luminous Source：Luxeontx, LG, CREE
• LED Driver：Meanwell, Inventronic
• Voltage：DC24V
• Transport Package：1unit,Carton
• Specification：CE, RoHS
• Trademark：ZGSM
• Origin：Linglong, Lin′an, Hangzhou, Zhejiang, China
• HS Code：940540900
• Production Capacity：5000PCS,Week

Electrical SpecificationsNominal Wattage100WNominal VoltageAC 100-240V, 50/60HzMaximum CurrentAC 1.03A-120V, 0.51A-240VOptimal Operating Temperature- 40 ºC to 50 ºCOperating Humidity10% to 90%Power Factor (PF)>0.9Driver Efficiency>90%Photometric SpecificationsCorrelated Color Temperature (CCT)3000-3500K, 4000-4500K, 5000-5500K, 6000-6500KLumen Output (3000-4500K)9000 lm ( +/- 5% )Lumen Output (5000-6500K)9500 lm ( +/- 5% )Color Rendering Index (CRI)Ra≥75Mechanical SpecificationsIP RatingIP65Lifetime50000 hoursHousingAnodized AluminumHeat RaditorAnodized AluminumLensPCFixture Dimension395 x 360 x 200 mm / 15.6 x 14.2 x 7.9 inchesFixture Weight9.9 kg / 21.8 lbsAperture DiameterΦ60 mm / Φ2.4 inchesPacking InformationsPacking Type1 unit / ctnPacking Dimension445 x 410 x 220 mm / 17.5 x 16.1 x 8.7 inchesPacking Weight12.5 kg / 27.6 lbs

Features
 1No UV12Significant energy savings2Long life13Wide input: 100 - 240V AC3Waterproof14Stable and efficient LED driver4Instant on/off15Significantly less generated heat5Mercury free16Resistant to shock and vibration6Maintenance free17Optimal heat sinking performance7Improved visibility18LED's maintain flux up to 100 lm/W8Ease of installation19Temperature compensation technology9Copper free aluminum20Exclusive appearance design with patents10Superior optical design21High quality and brightness LED light source11More than twice the average life of metal halide and high pressure sodium
