Good Quality 50-120W LED Solar Street Lamp Brled-S1
Yangzhou Bright Solar Solutions Co., Ltd.- Power Supply：24V
- Color Temperature：2700-6500K
- Lamp Body Material：Aluminum Alloy
- Power：50-120W
- Application：Square, Highway, Garden
- IP Rating：IP65
Base Info
- Model NO.：BRLED-S1
- Certification：CCC, CE, FCC, LVD, RoHS, SASO, Soncap
- With Light Source：Without Light Source
- Light Source：LED Light,High Power
- LED Type：Bridgelux,Epistar,CREE Is Available
- Transport Package：Carton
- Specification：LED-N01 STREET LIGHTS 120W
- Trademark：BR SOLAR; AS SOLAR
- Origin：China
- HS Code：94054090
- Production Capacity：20000PC,Month
Description
120W/24V14400LM 10M Height >40M >40LX 500W HPS 16800LM 12M Height >40M >40LX 600W HPS
LED Lamp Technical Data (AC)
LED Street Light Technical Descriptions(Model: LED-C03):
1. )Lamp Body: High-Pressure Die-Casting Aluminum. Corrosion Resistant, IP65 or IP68
2. )Application with Polyester Substance in its Surface.
3. )Reflector: High Purity Aluminum or Stainless Steel SS304, Mirror Polish.
4. )LED Cooler: Aluminum Material, Producing By Module
5. )Cover Glass: High Strength and High Transparent Toughened Glass
6. )Fastener Bolt and Screws: Stainless Steel, Anti-theft screw
7. )Ambient Temp: -40~+50°C; Humidity: 10%~95%
8. )Arm Diameter: 48 or 60mm
9. )Lumen: 100-110LM/W; 120-130LM/W; 140-150LM/W; Lifespan: 50000-100000Hrs
LED Lamp Technical Data (AC)
| Rated Power | Luminous Flux | Suitable for Pole | Lighting Distance | Central Illuminance | Replace |
| 130W | 15600LM | 10-12M Height | >40M | >40-45LX | 600W HPS |
| 140W | 16800LM | 10-12M Height | >40M | >40-45LX | 600W HPS |
| 150W | 18000LM | 10-12M Height | >40M | >40-45LX | 600W HPS |
| 160W | 19200LM | 10-12M Height | >40M | >40-45LX | 700W HPS |
| 170W | 20400LM | 10-12M Height | >40M | >40-45LX | 700W HPS |
| 180W | 21600LM | 10-12M Height | >40M | >45-50LX | 800W HPS |
| 200W | 24000LM | 10-12M Height | >40M | >45-50LX | 1000W HPS |
LED Street Light Technical Descriptions(Model: LED-C03):
1. )Lamp Body: High-Pressure Die-Casting Aluminum. Corrosion Resistant, IP65 or IP68
2. )Application with Polyester Substance in its Surface.
3. )Reflector: High Purity Aluminum or Stainless Steel SS304, Mirror Polish.
4. )LED Cooler: Aluminum Material, Producing By Module
5. )Cover Glass: High Strength and High Transparent Toughened Glass
6. )Fastener Bolt and Screws: Stainless Steel, Anti-theft screw
7. )Ambient Temp: -40~+50°C; Humidity: 10%~95%
8. )Arm Diameter: 48 or 60mm
9. )Lumen: 100-110LM/W; 120-130LM/W; 140-150LM/W; Lifespan: 50000-100000Hrs
High Lumen 160~170lm/W New Patented LED Street Light 60W IP68 Packing & Shipping
