• Model NO.：RB-STE-150W
• Certification：CE, EMC, ETL, FCC, LVD, RoHS, SAA, UL
• Input Voltage：220v
• With Light Source：With Light Source
• LED Chips Brand：Semileds
• IP Grade：IP66 Commercial Lighting Street
• CCT：3000K,4000K,5000K,6000K
• Luminous Flux：16500lm High Output LED Module
• Chip：Lumileds SMD3030
• Warranty：5 Year LED Shoe Box Lighting
• Driver：Meanwell Hlg
• Dimmable：0-10V,PMMA,Dali
• LED Lamp Use：Pole Mounted Luminaires
• Photocell：LED Street Light 150W
• Market：USA
• Transport Package：1PCS,Box
• Specification：CE,EMC,LVD,ETL,FCC
• Trademark：Rayborn
• Origin：China
• HS Code：9405409000
• Production Capacity：40, 000PCS,Month

Basic Info.

Model NO. RB-STE-150W Certification CE, EMC, ETL, FCC, LVD, RoHS, SAA, UL Input Voltage 220v With Light Source With Light Source LED Chips Brand Semileds IP Grade IP66 Commercial Lighting Street CCT 3000K/4000K/5000K/6000K Luminous Flux 16500lm High Output LED Module Chip Lumileds SMD3030 Warranty 5 Year LED Shoe Box Lighting Driver Meanwell Hlg Dimmable 0-10V,PMMA,Dali LED Lamp Use Pole Mounted Luminaires Photocell LED Street Light 150W Market USA Transport Package 1PCS/Box Specification CE/EMC/LVD/ETL/FCC Trademark Rayborn Origin China HS Code 9405409000 Production Capacity 40, 000PCS/Month

Product Description

Item No.: RB-STE-150W
Input Voltage: AC100~277V/AC 50-60Hz
LED Power: 150W
Chip: Lumileds CHip  130-140lm/W
Driver: Meanwell HLG/Invertronics EUG
Luminous Flux: 16500LM
LED Luminous Flux Warm White, Nature White, Pure White
LED Parking Lot light Viewing Angle: 85*135/90*140/100*140 degree
Color Temperature Warm White 3000K~3500K
Nature White 4000K~5300K, Pure White 6000K~7000K
Color Rendering Index: Ra≥ 80
Working Temperature: -35~55
IP Grade: IP66
10KV independent voltage protector
Working Life-span: 50000 H
The color of the lamp shell Silver
Certificate CE, EMC,UL & RoHS



150W LED Parking Light Features:

LED Parking lot light adopted optical light distribution, that is no glare, no light pollution, highly directional light and more even luminous beam.

1.Module lens design make the lamp with well suited lighting distributing for LED parking lot lighting.

2.Hollow out heat sink design make the lamp weight lighter and have good heat dissipation.

3.11 kinds of installation brackets.

4.Good-looking appearance. lamp luminous efficiency reaches 120lm/w.,

5.Lighting distribution curve: 85*135/90*140/100*140

6. Can be with photocell sensor and motion sensor.





Rayborn LED Parking lot Light Applications:
Widely used in factory, gymnasium, boatyard, billboards, buildings, lawns, landscaping, parking lot , the site of light project and decorative lighting projects etc.

RayborN LED Parking Lot Light Size:







 LED Parking lot Light Certification:

LED Parking Lot  Sea transportation:

Trade Terms:

1. Payment: T/T, L/C at sight, Western Union available
2. Samples can be available within 5-7 working days; Order: 10-20Days
3. Shipping freight is quoted under your requests
4. Shipping port: Shenzhen, China
5. Discouts are offered based on order quantities
6. MOQ: 50pcs

Rayborn Services:

1. Your inquiry related to our products or prices will be replied in 24hours.
2. OEM & ODM are welcomed, OEM brand is available.
3. Any defective products within warranty will get maintenance or replacement unconditionally.
4. Protect your sales area
