36*15W RGBWA 5in1 Multi-Color LED Wall Washer Light /LED Flood Light Waterproof IP 65
Guangzhou MS Lighting Co., Ltd.(China)- Emitting Color：Changeable
- Power：540W
- IP Rating：IP65
- Diffuser：Tempered Glass
- Beam Angle：6degree to 120degree
- Lifespan：10000 hours
Base Info
- Model NO.：LED 2003E
- Warranty：2 Years
- Certification：CE
- Electric Current Type：AC
- Input Voltage：110V-240V
- LED Lamp：36*15W RGBWA 5in1 Multi-Color LED Lamp
- DMX CH：8CH,5CH
- Base Material：Aluminum Alloy
- Transport Package：Carton,Flycase
- Specification：Dimension: 64*32*47cm Weight: 14kgs
- Trademark：MSLighting
- Origin：Guangzhou, China
- HS Code：94054090
- Production Capacity：500PCS,Week
Description
Basic Info.
Model NO. LED 2003E Warranty 2 Years Certification CE Electric Current Type AC Input Voltage 110V-240V LED Lamp 36*15W RGBWA 5in1 Multi-Color LED Lamp DMX CH 8CH/5CH Base Material Aluminum Alloy Transport Package Carton/Flycase Specification Dimension: 64*32*47cm Weight: 14kgs Trademark MSLighting Origin Guangzhou, China HS Code 94054090 Production Capacity 500PCS/WeekProduct Description
MODEL:LED 2003E: 36*15W RGBWA 5IN1 Multi-Color LED Lamp
Control signal: DMX512
Otection rating: IP 65
1) Input voltage: AC 90-130V/280V-240V/50-60Hz, auto change
2) Power: 1200W
3) DMX Channels: 8CH/5CH
Compatibility:
1. Color Range 16.7 million additive RGBWA Continuously variable intensity (256× 256× 256=16777216)
2. Dimming 0-100%with regulated constant color control
3. Strobe: 10 Flashed per second (any color)
4. Function: It is max mix color, color change, colors gradual change, flash, speed/luminance the adjustable, sound activity and Save function.
5.8channel Mode and 5channel Mode would change each other in every light
6. DMX Channels-8CH Mode:
CH 1 General Dimmer (1-255, from dart to light)
CH 2 Red (1-255, Dimmer, from dart to light)
CH 3 Green (1-255, Dimmer, from dart to light)
CH 4 Blue (1-255, Dimmer, from dart to light)
CH 5 White (1-255, Dimmer, from dart to light)
CH 6 AMBER (1-255, Dimmer, from dart to light)
CH 7 Strobe & Color change &color gradual change's open
CH 8 Strobe & Color change & color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)
7. DMX Channels-5CH Mode:
CH 1 Red (1-255, Dimmer, from dart to light)
CH 2 Green (1-255, Dimmer, from dart to light)
CH 3 Blue (1-255, Dimmer, from dart to light)
CH 4 White (1-255, Dimmer, from dart to light)
CH 5 AMBER (1-255, Dimmer, from dart to light)
