• Model NO.：STLFL001
• Application：Park, Square, Factory, Garden
• Certification：CE
• Operating Voltage：85-265V
• Transport Package：Color Box
• Specification：198*157*60,242*203*66,300*245*75,330*275*95mm
• Origin：China
• HS Code：94054090
• Production Capacity：100000PCS,Month

Basic Info.

Model NO. STLFL001 Application Park, Square, Factory, Garden Certification CE Operating Voltage 85-265V Transport Package Color Box Specification 198*157*60/242*203*66/300*245*75/330*275*95mm Origin China HS Code 94054090 Production Capacity 100000PCS/Month

Product Description



Power	Luminous Flux(LM)	Colour Temperature(K)	Input Voltage	Power Factor	Size (mm)	N.W.(KG)
STLFL001-20W	2000	3000-6500	85-265V	>0.95	198*157*60	1.5
STLFL001-30W	3000	3000-6500	85-265V	>0.95	242*230*66	2.7
STLFL001-50W	5000	3000-6500	85-265V	>0.95	300*245*75	4.4
STLFL001-70W	7000	3000-6500	85-265V	>0.95	330*275*95	5.4
STLFL001-80W	8000	3000-6500	85-265V	>0.95	330*275*95	5.4
STLFL001-100W	10000	3000-6500	85-265V	>0.95	330*275*95	5.4
STLFL001-180W	18000	3000-6500	85-265V	>0.95	330*275*95	5.4

Materials and features:
l         High pressure die-casting aluminum case,external,electro-static powder.
l         Heat-proof silicon gasket.
l         Tempered safety glass.
l         Adopt professional raster lens,light utilization efficiency reach 80%
l         Backside gearbox,helpful for Heat release of electric comporents.
Application:
l         Iumination of the façade of building,bullboards,parking places,grass lands and sculptures.
