• Model NO.：PL-SD-020-150
• Certification：CE, C-tick, RoHS, SAA
• Operating Voltage：150W
• Input Voltage：AC90V-305V
• LED Chips Brand：240 PCS Lumileds 3030SMD
• Transport Package：361*308*176mm
• Specification：321*268*136mm
• Trademark：Peony
• Origin：China

ParametersPackage  1PL-SD-037-100W Power: 100W
LED qty:184pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°CBeam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:309.6*116*190.6mm
ctn size:36.5x17.1x26cm
gross weight:2.8kg2PL-SD-037- 120W Power: 120W
LED qty:184pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°CBeam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:309.6*116*190.6mm
ctn size:36.5x17.1x26cm
gross weight:2.8kg3PL-SD-039-    150WPower: 150W
LED qty:368pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°CBeam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:356*117.6*341.9mm
ctn size:41.3x41.3x16.6cm
gross weight:5.5kg4PL-SD-039-    200W Power: 200W
LED qty:368pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°C Beam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:356*117.6*341.9mm
ctn size:41.3x41.3x16.6cm
gross weight:5.5kg5PL-SD-039-    240W Power: 240W
LED qty:368pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°C Beam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:356*117.6*341.9mm
ctn size:41.3x41.3x16.6cm
gross weight:5.5kg6PL-SD-039-    300W Power: 300W
LED qty:552pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°C Beam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size: 356*117.6*473.9mm
ctn size:54.5x41.3x16.6cm
gross weight:7.5kg7PL-SD-039-   360W Power: 240W
LED qty:368pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°C  Beam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size: 356*117.6*473.9mm
ctn size:54.5x41.3x16.6cm
gross weight:7.5kg8PL-SD-039-   400W Power: 400W
LED qty:736pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°CBeam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:356*117.6*605.9mm
ctn size:66.9x41.3x16.6cm
gross weight:9.5kg9PL-SD-039-   480W Power:480W
LED qty:736pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°CBeam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:356*117.6*605.9mm
ctn size:66.9x41.3x16.6cm
gross weight:9.5kg10PL-SD-039-   400W01 Power: 400W
LED qty:736pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°C Beam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:650*117.6*335.4mm
ctn size:70.5x40.8x16.6cm
gross weight:9.5kg11PL-SD-039-   480W01 Power:480W
LED qty:736pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°C Beam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:650*117.6*335.4mm
ctn size:70.5x40.8x16.6cm
gross weight:9.5kg12PL-SD-039-   600W Power: 600W
LED qty:1104pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°CBeam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:650*117.6*467.4mm
ctn size:70.5x54x16.6cm
gross weight:11.0kg13PL-SD-039-   720W Power: 720W
LED qty:1104pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°CBeam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:650*117.6*467.4mm
ctn size:70.5x54x16.6cm
gross weight:11.0kg14PL-SD-039-   800W Power: 800W
LED qty:1472pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°C Beam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:650*117.6*599.4mm
ctn size:70.5x67x16.6cm
gross weight: 17.5kg15PL-SD-039-   1000W Power: 1000W
LED qty:1472pcs3030smd
Input Votage:AC90V-305V
Material: Aluminum + acrylic lens
IP grade:IP65, Working temperature :-40°C-50°CBeam angle:60°/90°/140x100°/120°
lumens efficiency:130-140LM/Wlm/W
PF:> 0.95
CRI: Ra>70/80
CCT:2700-6500K
Life:50000Hlamp size:650*117.6*599.4mm
ctn size:70.5x67x16.6cm
gross weight: 17.5kg






 Application:

Widely used in household, hotel room ,show room, corridor, hotel lobby, public place of entertainment andso on

Our Service:1>. Fast deilvery: For samples 3 working day. For bulk order: 5-12working days. We produce over 2000PCS LED spotlight /day.2>. Good Quality control: We have our own LEDs Encapsulation room, we produce LED drivers by ourselves. All 3 years warranty with UL, cUL, ETL, Energy-star, PSE, BV CE certificates.3>. Mature OEM Service: With 8 years LED lighting manufacture.

We can suppy FREE laser print label, color box design etc.



FAQ

Q: Whether the  LED lights really have 50,000 hours lifespan?

A: 50,000 or longer lifespan is only theory from lab test.But due to working environment are different from

in lab,actual lifespan is only  <=30,000hours. Meanwhile it can also be 50,000 hours lifespan if it adopt very good material.

Q: For same power,why different suppliers with different brightness?

A: Different chips,or same chip but different brightness version.The brightness will be different.But for same chip

and same brightness version,the brightness will be slight difference.But please make clear the brightness difference

between LEDs and lamp fixture.

Q:What is colour temperature?A: Kelvin is a way to measure "temperature", the light from LED lights emit a certain color, which we have catagorized

in CTT(kelvin).For example, a warmer (lower color temperature) light is often used in public areas to promote relaxation,

while a cooler (higher color temperature) light is used to enhance concentration in offices.

Q: What is CRI?

A: CRI is a figure which feedback the real objects colors.Higher CRI with higher cost.

Q: What is PF and efficiency?

A: PF and efficiency is to feedback the driver electrical performance.Higher PF and efficiency with higher coste other questions, please feel free to contact us, you will get reply at the first time
