48*1W/3W RGB LED Stage Blinder Light
Guangzhou MS Lighting Co., Ltd.(China)- Emitting Color：RGB
- IP Rating：IP33
- Diffuser：Polycarbonate
- Beam Angle：6-120degree
- Lifespan：50000 hours
- Certification：CE, EMC, LVD, RoHS
Base Info
- Model NO.：LED-4E-RGB1W,3W
- Electric Current Type：AC
- Input Voltage：90-245V
- DMX Channel：3CH,6CH
- Switch Power Supply：Built-in and Auto Switching
- Control Panel：Digital 4 Characters Alphanumeric
- Connector：3-Pinxlr (in and out)
- No.of LED：48*1W,48*3W
- Electronic Dimmer：1-100% Linear Dimmer
- Electronic Strobe：1-30 Flashes,Second
- Cooling：Casing as Heat Sink Plus Noiseless Fans
- Flicker Free：Refresh Rate >1000 Hz
- Key Point：Temperature-Protected Easily
- Transport Package：Carton,Flycase
- Specification：CARTON: L51*H46*W19cm G. W: 7.5kg
- Trademark：MSLighting
- Origin：GuangZhou, China
- HS Code：94054090
- Production Capacity：500pcs,week
Description
| Model | LED 4E -1W/LED 4E-3W (48*3W) RGB |
| Housing Material | Aluminum |
| Housing Color | Black/White |
| Aperture Cover | Aluminum |
| Operating voltage | 90-130V AC / 176-254V AC |
| Output voltage | DC 24-36V |
| Control Modes | Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization |
| Lamp Luminous Efficiency(lm/w): | 99% |
| Usage: | Theatres, stage , robust housing |
| Certification: | CE,EMC, LVD, RoHs |
| LED Life Time | 80000-100,000 hours |
| Beam Angle | 6-120degree to choose |
| Power Consumption | 70W/200W |
| Light Projecting Distance | 5-200M |
| IP Rating | Indoor |
| Operating Temperature | -20ºC-+45 ºC |
| Power In: | Fixed |
| CRI (Ra>): | 95 |
| Packing Dimension | 52x52x52.5cm |
| Gross Weight | 10.00KGSs |
| warranty: | 2 year |
| Compatibility: | |
| 1. Color Range:16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216) | |
| 2. Dimming 0-100%with regulated constant color control | |
| 3.Strobe: 10 Flashed per second (any color) | |
| 4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable and Save function. | |
| 5. 6 channel Mode and 3channel Mode would change each other in every light | |
| 6. 6CH Mode DMX Value | CH 1 _ General dimmer (1-255, from dart to light) |
| CH 2_ Red (1-255, Dimmer, from dart to light) | |
| CH 3 _ Green (1-255, Dimmer, from dart to light) | |
| CH 4_Blue (1-255, Dimmer, from dart to light) | |
| CH 5_ Strobe & Color change/ color gradual change open | |
| CH 6 _Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast) | |
| 7. 3CH Mode DMX Value | CH 1_ Red (1-255, Dimmer, from dart to light) |
| CH 2 _ Green (1-255, Dimmer, from dart to light) | |
| CH 3_Blue (1-255, Dimmer, from dart to light) | |
| 8.Control modes | 0: Sound activity mode |
| 1. DMX control mode | |
| 2. Adjusting the color manual | |
| 3. Adjusting the brightness manual | |
| 4. Adjusting the strobe manual | |
| 5. Adjusting the strobe speed manual | |
| 6. Master-slave control mode, as the master | |
| 7. Sound activity synchronization mode | |
| 8. Adjusting color's gradual change manual | |
| 9. Adjusting gradual change's speed. | |
| 9. Thermal: | Maximum ambient temperature: 40° |
| Maximum housing temperature: 60° | |
| Packaging & Delivery | |
| Packaging Detail: | Standard Export packing by carton or OEM package |
| Delivery Detail: | 2-5 days for sample , 5-12 days for mass quantity order |
| Shipping | By DHL, UPS, FedEx, EMS or TNT, boat ,Air. |
| Guarantee | we guarantee that all the product have been shipped after the testing , if there any damage caused in transit , we can not control the entire process , if so , we are happy to communicate with you friendly solution. |
| Items have 2 YEAR warranty. ( Except lamp-house). | |
| Note | We can declare it as a 'GIFT/Sample' with a lower value Which you may reduce tax. But This lower price does not reflect the total price you paid or the market value of the product |
