80W Solar Street Lighting System
Yangzhou Bright Solar Solutions Co., Ltd.- Power Supply：Solar
- Lamp Body Material：Aluminum
- Application：Square, Highway, Garden, City Center for Mainroad
- IP Rating：IP65
- Certification：CCC, CE, CQC, EMC, FCC, LVD, RoHS, SASO
- Input Voltage：24v
Base Info
- Model NO.：6-8-10M-S3
- With Light Source：With Light Source
- LED Chips Brand：Epistar
- Lighting Effect：Equal to 350W High Pressure Sodium Lamp
- Designing Points：with Battery Bury Under Ground
- IP Level：IP65,IP68 Against Thief
- Transport Package：70PC,40′hq Container
- Specification：80W LED Design
- Trademark：BRIGHT; AS SOLAR; BR SOLAR
- Origin：China
- HS Code：94054090
- Production Capacity：5000PC,Month
Description
Specification for 80W LED Solar Street Lighting SystemPart Name and Lifespan Technical Specification Solar Panel:
Lifespan:20-25 years 160W*2PC Polycrystalline. High Efficiency. A-class
Adding Aluminum Frame, Tempered Glass. Gelled Battery
Lifespan:5-8 years 180Ah/12V*2PC, Gelled battery, Sealed Type.
Deep cycle. Maintenance Free Intelligent Solar Controller
Lifespan:5-10 years 15A/24V,IP65. Automatic Light and Time Control
Over-charging/discharging Protection
Reverse-connection Protection
Switch on Automatically with Light Sensor;
Switch off after designed Hours later.(11-12 Hrs) Light source: High Power LED
Lifespan: More than 50000-100000Hrs 80W LED, White Color, Cree Chip, 9600LM,6500K,IP65,High Power, High Brightness. Lamp Housing:
Lifespan: More than 20 years Die-casted Aluminum, IP65
High transmittance & Density toughened glass, Battery Box: PVC material, Bury underground, Waterproof and Heat-dissipative GI Pole System:
Lifespan: More than 20 years
10M Height, tapered Pole, Steel,
Hot-Dip Galvanized. Plastic Coated, Rust Proof,
With Arm, Bracket, Flange, Fittings, Cable, Etc
Resistant to Wind: ≥150KM/H
Lifespan:20-25 years
Adding Aluminum Frame, Tempered Glass.
Lifespan:5-8 years
Deep cycle. Maintenance Free
Lifespan:5-10 years
Over-charging/discharging Protection
Reverse-connection Protection
Switch on Automatically with Light Sensor;
Switch off after designed Hours later.(11-12 Hrs)
Lifespan: More than 50000-100000Hrs
Lifespan: More than 20 years
High transmittance & Density toughened glass,
Lifespan: More than 20 years
Hot-Dip Galvanized. Plastic Coated, Rust Proof,
With Arm, Bracket, Flange, Fittings, Cable, Etc
Resistant to Wind: ≥150KM/H
