• Model NO.：LED 2009K
• Warranty：2 Years
• Certification：CE
• Electric Current Type：AC
• Input Voltage：110V-240V
• LED Lamp Quantity 1：18*18W Rgbwauv 6in1 Multi-Color LED Lamp
• Base Material：Aluminum Alloy
• Transport Package：Carton,Flycase
• Specification：Dimension: 56*25*28cm N. G.: 6KGS
• Trademark：MSLighting
• Origin：Guangzhou, China
• HS Code：94054090
• Production Capacity：500PCS,Week

Basic Info.

Model NO. LED 2009K Warranty 2 Years Certification CE Electric Current Type AC Input Voltage 110V-240V LED Lamp Quantity 1 18*18W Rgbwauv 6in1 Multi-Color LED Lamp Base Material Aluminum Alloy Transport Package Carton/Flycase Specification Dimension: 56*25*28cm N. G.: 6KGS Trademark MSLighting Origin Guangzhou, China HS Code 94054090 Production Capacity 500PCS/Week

Product Description

MODEL: LED 2009K: 18*18W RGBWAUV 6IN1 Multi-Color LED Lamp

Control signal: DMX512
Power consumption: 324W
Protection rating: IP 65
1) Input voltage: AC 90-130V/280V-240V/50-60Hz, auto change
2) Power: 350W
3) LED size: 18W RGBWAUV 6IN1 Multi-Color LED Lamp
4) DMX Channels: 9CH/6CH

Compatibility:
1. Color Range 16.7 million additive RGB colors; Continuously variable intensity (256× 256× 256=16777216)
2. Dimming 0-100%with regulated constant color control
3. Strobe: 10 Flashed per second (any color)
4. Function: It is max mix color, color change, colors gradual change, flash, speed/luminance the adjustable, sound activity and Save function.
5.8channel Mode and 5channel Mode would change each other in every light

6. DMX Channels-9CH Mode:
CH 1 General Dimmer  (1-255, from dart to light)
CH 2 Red      (1-255, Dimmer, from dart to light)
CH 3 Green   (1-255, Dimmer, from dart to light)
CH 4 Blue     (1-255, Dimmer, from dart to light)
CH 5 White    (1-255, Dimmer, from dart to light)
CH 6 Amber   (1-255, Dimmer, from dart to light)
CH 7 UV       (1-255, Dimmer, from dart to light)
CH 8 Strobe & Color change &color gradual change's open
CH 9 Strobe & Color change & color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)

7. DMX Channels-6CH Mode:
CH 1 Red     (1-255, Dimmer, from dart to light)
CH 2 Green  (1-255, Dimmer, from dart to light)
CH 3 Blue     (1-255, Dimmer, from dart to light)
CH 4 White   (1-255, Dimmer, from dart to light)
CH 5 Amber  (1-255, Dimmer, from dart to light)
CH 6 UV       (1-255, Dimmer, from dart to light)
