96*4W/63*10W RGBW 4in1 Multi-Color LED City Color Light/LED Wall Washer Light Waterproof IP 54
Guangzhou MS Lighting Co., Ltd.(China)- Emitting Color:RGBW,a 4in1
- Power:400W,680W
- IP Rating:IP54
- Diffuser:Tempered Glass
- Beam Angle:25°
- Lifespan:80000
Base Info
- Model NO.:LED 011F,LED 011G
- Warranty:2 Years
- Certification:CE
- Electric Current Type:AC
- Input Voltage:100V,120V,200V,220V ,230V,240VAC, 50,60Hz
- Color:RGBW,a 4-in-1
- Base Material:Aluminum Alloy
- Transport Package:Carton,Flycase
- Specification:Dimensions: 77*52*62CM Weight: 28.00kg
- Trademark:MSLighting
- Origin:Guangzhou, China
- HS Code:94054090
- Production Capacity:500PCS,Week
Description
Specification:Model LED 011F LED 011G NO. of LED 96*4W RGBW 4IN1 MULTI-CHIP LED LAMP 63*10W RGBW 4IN1 MULTI-CHIP LED LAMP Power Consumption 520W 720W DMX Channel 7CH/4CH 7CH/4CH Control panel Digital 4 characters alphanumeric Housing Color Black Operating voltage 100-230V AC Control Modes Direct DMX 512, Master/slave. Stand alone. Sound Activity Connector 3-PinXLR (In and Out) LED Life Time 80000-100, 000 hours Beam Angle 25° /30° Light Projecting Distance 5-150M IP Rating Outdoor IP 65 Operating Temperature -20° c-+45° c Packing Dimension 77*52*62CM Gross Weight 28.00KGS Compatibility: 1. Color Range: 16.7 million additive RGBW colors; continuously variable intensity (256× 256× 256=16777216) 2. Dimming 0-100%with regulated constant color control 3. Strobe: 10 Flashed per second (any color) 4. Function: it is max mix color, color change, flash, speed/luminance the adjustable 5.7channel Mode and 4channel Mode would change each other in every light 6.7CH Mode DMX Value CH 1_ General dimmer (1-255, from dart to light) CH 2_ Red (1-255, Dimmer, from dart to light) CH 3_ Green (1-255, Dimmer, from dart to light) CH 4_ Blue (1-255, Dimmer, from dart to light) CH 5_ White/AMBER (1-255, Dimmer, from dart to light) CH 6_ Strobe & Color change/ color gradual change open CH 7_ Strobe & Color change& color gradual change' s speed adjustment (1-255, Speed adjustment, from slow to fast) 7.4CH Mode DMX Value CH 1_ Red (1-255, Dimmer, from dart to light) CH 2_ Green (1-255, Dimmer, from dart to light) CH 3_ Blue (1-255, Dimmer, from dart to light) CH 4_ White/Amber (1-255, Dimmer, from dart to light) 8. Control modes 0: sound activity mode 1. DMX control mode 2. Adjusting the color manual 3. Adjusting the brightness manual 4. Adjusting the strobe manual 5. Adjusting the strobe speed manual 6. Master-slave control mode, as the master 7. Sound activity synchronization mode 8. Adjustingcolor' s gradual change manual 9. Adjustinggradual change' s speed
