• Model NO.：NTXY-TGD200
• Specification：325*425*150
• Trademark：NANTE
• Origin：China
• Production Capacity：50000

Basic Info.

Model NO. NTXY-TGD200 Specification 325*425*150 Trademark NANTE Origin China Production Capacity 50000

Product Description

LED Overhead Crane Spot/Line Light For Warehouse Safety
    overhead crane warning LED projects a solid white, blue or red tightly focused spotlight on the floor to alert pedestrians to the hook's location. In addition, the spotlight aids precise positioning for crane operators by providing a framing reference between the floor and hook.
LED Spotlight warning lights  improve safety on overhead cranes:
1. Reduce incidences of human error - ensures pedestrians are aware of moving load.
2. Pedestrian sees projected line or spot on floor - knows his proximity to the moving load.
3. Very effective for overhead cranes in areas with many pedestrians.
4. Beeping audible alarms do NOT provide a pedestrian with a sense of proximity to the load on the crane.
5. Crane operators have a new "frame of reference" of the exact position of load/hook above floor.
6. Significantly improves operator control of the load, especially when exact positioning is required.
7. Operators do not have to take their eyes off the crane block or load to know trolley is centered over the load.
8.Snap-on lens cover creates square "box" around load/hook on floor below clear "danger area".
9. Warns pedestrians from walking under suspended load.
10. When a load on a crane is stopped suddenly.
11. Workers concentrating on their job at hand and may NOT see moving load in their area.
12. Crane operators concentrate on the load they are handling and may NOT see workers.
13. Powerful 24 MAXI LED 120 watt light projects RED, BLUE or WHITE spot or line -with lens cover.
Blue or Red Spotlight Specification:

Power	120Watts-84Watts
Voltage	9-60V DC
Lumens	12000Lm 8400Lm
LEDs	24(Cree LED)
LED Color Temperature	6000K
Beam Type	Pencil Beam
Working Life	50000Hours
Size	(325 X 425 X 150mm)
Waterproof	IP67
Working Temperature	-45 ~85°C
Material	Aluminum die-cast housing
Packaging	Individually boxed with foam
Adjustable Mounting Bracket	150 degree up/down
Lifetime Hours	Up to 30,000 50,000 hours
Cable Length	3.3 meters (10')
