• Model NO.：LED 011,011A,011C,011D,011E
• Warranty：2 Years
• Certification：CE, EMC, LVD, RoHS, SGS
• Electric Current Type：AC
• Input Voltage：90-245VAC 50,60Hz
• DMX Channel：3CH,6CH,4CH,7CH
• Switch Power Supply：Built-in and Auto Switching
• Control Panel：Digital 4 Characters Alphanumeric
• Connector：3 or 5-Pinxlr (in and out)
• Electronic Dimmer：1-100% Linear Dimmer
• Electronic Strobe：1-30 Flashes,Second
• Cooling：Entire Casing as Heat Sink (No Fans)
• Flicker Free：Refresh Rate >1000 Hz
• Key Point：Temperature-Protected Easily
• Usage：Theatres, Stage , Robust Housing
• Transport Package：Carton,Flycase
• Specification：77*52*62cm Weight: 28KG
• Trademark：MSLighting
• Origin：Guangzhou, China
• HS Code：94054090
• Production Capacity：500PCS,Week

LED 011 (120*1W) RGBW/ALED 011A (120*3W) RGBW/ALED 011C (156*1W) RGBW/ALED 011D (156*3W) RGBW/ALED 011E (120*5W) RGBW/AHousing MaterialAluminumAluminumAluminumAluminumAluminumHousing ColorBlackBlackBlackBlackBlackAperture CoverPMMAPMMAPMMAPMMAPMMAOperating voltage90-130V AC / 176-254V AC90-130V AC / 176-254V AC90-130V AC / 176-254V AC90-130V AC / 176-254V AC90-130V AC / 176-254V ACPower  Switch Power SupplySwitch Power SupplySwitch Power SupplySwitch Power SupplySwitch Power SupplyLED current320mA680mA320mA680mA1.4AControl ModesDirect DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronizationDMX Channel7CH/4CH7CH/4CH7CH/4CH7CH/4CH7CH/4CHControl panelDigital 4 characters alphanumericDigital 4 characters alphanumericDigital 4 characters alphanumericDigital 4 characters alphanumericDigital 4 characters alphanumericConnector3-PinXLR (In and Out)3-PinXLR (In and Out)3-PinXLR (In and Out)3-PinXLR (In and Out)3-PinXLR (In and Out)NO.of LED120*1W LEDS (24R/ 32B/ 32G/ 32W)120*3W LEDS  (24R/ 32B/ 32G/ 32W)156*1W LEDS (39R/ 39B/ 39G/ 39W)156*3W LEDS  (39R/ 39B/ 39G/ 39W)120*5W LEDS  (30R/ 30B/ 3G/ 30W)LED Life Time80000-100,000 hours80000-100,000 hours80000-100,000 hours80000-100,000 hours80000-100,000 hoursBeam Angle25°/30°/45°/60°25°/30°/45°/60°25°/30°/45°/60°25°/30°/45°/60°25°/30°/45°/60°Power Consumption160W420W210W520W520WLight Projecting Distance20-100M20-200M20-120M20-250M20-400MIP RatingOutdoor, Waterproof, IP 54Operating Temperature20ºC-+45ºCSize770*520*620mmWeight28KGCompatibility:1.  Color Range: 16.7 million  additive  RGBW  colors; continuously  variable  intensity (256×256×256=16777216)2. Dimming 0-100%with regulated constant color control3.Strobe: 10 Flashed per second (any color)4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable, and save function5. 7channel Mode and 4channel Mode would change each other in every light6. 7CH Mode DMX ValueCH 1_ General dimmer    (1-255, from dart to light)CH 2_ Red               (1-255, Dimmer, from dart to light)CH 3_ Green            (1-255, Dimmer, from dart to light)CH 4_ Blue               (1-255, Dimmer, from dart to light)CH 5_ White             (1-255, Dimmer, from dart to light)CH 6_ Strobe & Color change/ color gradual change openCH 7_ Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)7. 4CH Mode DMX ValueCH 1_ Red              (1-255, Dimmer, from dart to light)CH 2_ Green           (1-255, Dimmer, from dart to light)CH 3_ Blue              (1-255, Dimmer, from dart to light)CH 4_ White             (1-255, Dimmer, from dart to light)8. Control modes0. Sound activity mode1. DMX control mode2. Adjusting the color manual3. Adjusting the brightness manual4. Adjusting the strobe manual5. Adjusting the strobe speed manual6. Master-slave control mode, as the master7. Sound activity synchronization mode8.Adjustingcolor's gradual change manual9.Adjustinggradual change's speed.
