120*3in1tricolor RGB Multi-Color LED City Color Light/LED Wall Washer Light
Guangzhou MS Lighting Co., Ltd.(China)- Emitting Color:RGB 3in1
- Power:420W
- IP Rating:IP54
- Diffuser:Tempered Glass
- Beam Angle:25°
- Lifespan:80000
Base Info
- Model NO.:LED 011B
- Warranty:2 Years
- Certification:CE
- Electric Current Type:AC
- Input Voltage:100V,120V,200V,220V ,230V,240VAC, 50,60Hz
- Color:RGB 3-in-1
- Base Material:Aluminum Alloy
- Transport Package:Carton,Flycase
- Specification:Dimensions: 77*52*62CM Weight: 28.00kg
- Trademark:MSLighting
- Origin:Guangzhou, China
- HS Code:94054090
- Production Capacity:500PCS,Week
Description
Specification:ModelLED 011B (120*RGB 3-IN-1 MULTI-CHIP LED)DMX Channel6CH/3CHControl panelDigital 4 characters alphanumericHousing ColorBlackOperating voltage100-230V ACControl ModesDirect DMX 512, Master/slave. Stand alone. Sound ActivityConnector3-PinXLR (In and Out)NO. of LED120*RGB 3-IN-1 MULTI-CHIP LED LAMPLED Life Time80000-100, 000 hoursBeam Angle25° /30°Power Consumption420WLight Projecting Distance5-150MIP RatingIndoor,Outdoor,IP54Operating Temperature-20° c-+45° cPacking Dimension77*52*62CMGross Weight28.00KGSCompatibility:1. Color Range: 16.7 million additive RGB colors; continuously variable intensity (256× 256× 256=16777216)2. Dimming 0-100%with regulated constant color control3. Strobe: 10 Flashed per second (any color)4. Function: it is max mix color, color change, flash, speed/luminance the adjustable5.6channel Mode and 3channel Mode would change each other in every light6.6CH Mode DMX ValueCH 1_ General dimmer (1-255, from dart to light)CH 2_ Red (1-255, Dimmer, from dart to light)CH 3_ Green (1-255, Dimmer, from dart to light)CH 4_ Blue (1-255, Dimmer, from dart to light)CH 5_ Strobe & Color change/ color gradual change openCH 6_ Strobe & Color change& color gradual change' s speed adjustment (1-255, Speed adjustment, from slow to fast)7.3CH Mode DMX ValueCH 1_ Red (1-255, Dimmer, from dart to light)CH 2_ Green (1-255, Dimmer, from dart to light)CH 3_ Blue (1-255, Dimmer, from dart to light)8. Control modes0: sound activity mode1. DMX control mode2. Adjusting the color manual3. Adjusting the brightness manual4. Adjusting the strobe manual5. Adjusting the strobe speed manual6. Master-slave control mode, as the master7. Sound activity synchronization mode8. Adjustingcolor' s gradual change manual9. Adjustinggradual change' s speed
