• Model NO.：YH2118T YH2136T YH2236T
• Certification：CCC, CE, CQC, C-tick, EMC, Energy Star, GS, LVD, RoHS, SAA, UL, VDE
• Operating Voltage：220-240V
• Input Voltage：110V
• LED Chips Brand：Samsung
• Lf：280 800 1000
• IP Rate：65
• Clip Q′ty(PCS)：4 8 10
• Lifetime：50000hours
• Main Material：Polycarbonate
• Qualification Certificate：CE RoHS GS ENEC SAA CE UL
• Transport Package：in The Box,Cotton
• Specification：GS SAA CCC UL EMC ROHS CE CUL etc
• Trademark：Yuan Hui
• Origin：Cixi, Zhejiang, China
• HS Code：9405409000
• Production Capacity：10000PCS,Month

Basic Info.

Model NO. YH2118T YH2136T YH2236T Certification CCC, CE, CQC, C-tick, EMC, Energy Star, GS, LVD, RoHS, SAA, UL, VDE Operating Voltage 220-240V Input Voltage 110V LED Chips Brand Samsung Lf 280 800 1000 IP Rate 65 Clip Q′ty(PCS) 4 8 10 Lifetime 50000hours Main Material Polycarbonate Qualification Certificate CE RoHS GS ENEC SAA CE UL Transport Package in The Box/Cotton Specification GS SAA CCC UL EMC ROHS CE CUL etc Trademark Yuan Hui Origin Cixi, Zhejiang, China HS Code 9405409000 Production Capacity 10000PCS/Month

Product Description

Product advantage:


Three lamp is waterproof, dustproof, anticorrosion: the three. Using special oxidation resistant anticorrosive material and silicon rubber sealing ring to realize lamp protection requirements. This lamp control circuit on board anti-corrosion, waterproof, anti oxidation treatment, the electrical box sealing characteristics of cooling ability is weak, the wisdom of three proofings lamp special temperature control circuit, reduce the power converter working temperature of electrical isolation protection, connectors for double insulation treatment, to ensure safe and reliable line. According to the actual working environment of three proofings lamp on the lamp box door, the surface of Nano Spray anti-corrosion moisture-proof treatment, prevent dust and moisture entering




1.Parameters



Model No.	Lamps	Clip Q'ty   (PCS)	Product Size L*W*H(mm)	LF(mm)	Q'ty/CTN   (PCS)	Carton Size(mm)
YH2118T	1*18W T8 G13	4	670*76*90	280	12	695*265*300
YH2118T	2*18W T8 G13	4	670*120*90	280	9	695*400*225
YH2136T	1*36W T8 G13	8	1270*76*90	800	9	1295*265*225
YH2236T	2*36W T8 G13	8	1270*120*90	800	8	1295*270*300
YH2158T	1*58W T8 G13	10	1570*76*90	1000	9	1595*265*225
YH2258T	2*58W T8 G13	10	1570*120*90	1000	6	1595*270*225

2.Product Description:


  1.Natural silicom gel gasket used in the housing.

  2.PC clips or S/S clips for locking and waterproof cable gland on side of the housing to ensure good waterproof function.

  3.Many types combinations between housing(ABS,PC)and diffuser(PS,PMMA,PC) to meet different requests.

  4.PC wire clips to ensure electrical safety.

  5.Prismatic diffuser with unique shape design to get average ray, efficient usage of light and good dazzle-proof effect.

  6.Easy and quick to installation under ceiling or on surface.

  7.Plastic gear tray holder connected to the housing for easy maintence.




Product description



Housing : Injection moulded , high mechanical resistant ,delf-xctinguishing ,RL7035 light polycarbonate ; ( ABS option)
Diffuser : Injection moulded ,V0 self-exctinguishing ,UV stabilised transparent polytection ;prismatic inside for better light control ;(PMMA for option)
Reflector ; high quality iron sheet whit whit power coating
Lampholder : T8-G13 ,Polycarbonate and High quality copper material : tube rotstion protection: VDE and ENEC certified .
Ballast :EEQ=B2 magnetic ballast or EE1=A2 electronic ballast (OSRAM ,TRIDONIC brand )
Terminal block : 3poles screw type ,or 3poles screwless type :(5poles for option)
Clip :  Polycarbonate clips or Stainless clips for option;
Mounting bracket : Easy and qiuck to install under celling or on surface .
Hanger :Plastic gear tray holder connected to the housing for easy maintenace .
Accessory bag : Rubber gromment ,PG13.5 cable gland , expansion and screws

Applications : Approved for indoor use or outdoor use which need waterproof , dustproof and moistureproof
Friendly reminder : 1)must not be installed on surfaces subject to strong vibrations : must not be installed
                                   2)when using PC dffuser ,don't use moderately to strong alkaline or acidic material or solvents or cleaning agents which attack PC material
                                   3)special enviroment using, pls contact us .
