• Model NO.：LED 2000D
• Warranty：2 Years
• Certification：CE
• Electric Current Type：AC
• Input Voltage：100V,120V,200V,220V ,230V,240VAC, 50,60h
• Color：RGB,RGBW,RGBA,UV,Wa
• Base Material：Aluminum Alloy
• Transport Package：Carton,Flycase
• Specification：Dimension: 75*34*31cm, 15kgs
• Trademark：MSLighting
• Origin：Guangzhou, China
• HS Code：94054090
• Production Capacity：500PCS,Week

ModelLED 2000DHousing MaterialAluminumHousing ColorBlackAperture CoverPMMAOperating voltage90-130V AC / 176-254V ACPower  Switch Power SupplyLED current680mAControl ModesDirect DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronizationDMX Channel6CH/3CH,7CH/4CHControl panelDigital 4 characters alphanumericConnector3-PinXLR (In and Out)NO.of LED72*5W LEDS (36R/ 36B/ 36G)/(27R27B27G27W)LED Life Time80000-100,000 hoursBeam Angle25°/30°/45°/60°Power Consumption400WLight Projecting Distance50-200MIP RatingOutdoor, Waterproof, IP 65Operating Temperature20ºC-+45ºCDimensions740*300*310 (mm)Weight13.00 (kg)Packing Dimension750*340*310 (mm)Gross Weight15.00 (Kg)Compatibility:1.  Color Range: 16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216)2. Dimming 0-100%with regulated constant color control3.Strobe: 10 Flashed per second (any color)4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable, and save function5. 6channel Mode and 3channel Mode would change each other in every light6. 6CH Mode DMX ValueCH 1 - General dimmer  (1-255, from dart to light)CH 2 - Red                (1-255, Dimmer, from dart to light)CH 3 - Green            (1-255, Dimmer, from dart to light)CH 4 - Blue                (1-255, Dimmer, from dart to light)CH 5 - Strobe & Color change/ color gradual change openCH 6 - Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)7. 3CH Mode DMX ValueCH 1 - Red              (1-255, Dimmer, from dart to light)CH 2 - Green           (1-255, Dimmer, from dart to light)CH 3 - Blue              (1-255, Dimmer, from dart to light)8. Control modes0: sound activity mode1. DMX control mode2. Adjusting the color manual3. Adjusting the brightness manual4. Adjusting the strobe manual5. Adjusting the strobe speed manual6. Master-slave control mode, as the master7. Sound activity synchronization mode8 .Adjusting color's gradual change manual9. Adjusting gradual change's speed.Each Package Included:1* LED2000D with Signal Cable :3-PinXLR DMX In and Out + Water Power cable: Power Cable screw water proof connectors in and out (2ft cable)1* User Manual1* Power cable: 3 Pin plug and screw water proof connector on other side. (2ft cable)2* pyrocondensation.cannula (0.66ft = 20cm)1* Waterproof connector's cover for Power cable
