• Model NO.：LMF-36W
• Warranty：5 Years
• Certification：CE, EMC, GS, LVD, RoHS, SAA, UL
• Voltage：220V
• With Light Source：With Light Source
• Size：1560*120*108mm
• Driver：Osram Driver
• LED Chips：Lextar 5630 Chips
• Certificates：UL,Dlc
• Transport Package：Inner Box+Carton Box
• Specification：CE-LVD, EMC, ROHS, GS, ENEC, C-TICK, UL,
• Trademark：Yuanhui
• Origin：Ningbo, China
• HS Code：9405409000
• Production Capacity：50000PCS,Month

>80
2700k-3000k

4000k-4500k

6000k-6500k
600*120*108
CE, EMC,
ROHS, GS,
CB, ENEC, SAA, C-TICK,
UL, CUL
DLC
IK08, IP66

LMF24-60050PCS2290lmLMF24-116050PCS  2360lm1160*120*108LMF36-116075PCS3540lmLMF48-1160104PCS4540lmLMF34-156078PCS3030lm1560*120*108LMF48-1560120PCS5150lmLMF70-1560156PCS5600lm

Factory Pictures:




Voltage: AC 100V-240V, 277v
Frenquency:50/60Hz
PF>0.9
LED:SMD5630
LED Driver: OSRAM or Meanwell led driver
LED lifetime: More than 50000hours
Ta: -25degree to 50 degree
IP Rate: IP66
Class: II
Specification of IP66 waterproof led lighting:
Imported plastic material (heat conduction) and Aluminum plate (heat dissipation) for housing
LED: 5630 Samsung chips
Driver: Meanwell LPF series or OSRAM led driver
Opal or transparent polycarbonate diffuser with UV protection for an optimum light distribution
Impact resistance: IK08
Glow Wire Test: 850 degree
Natural silicon gasket to ensure IP66 rate
Stainless bracket fixation: Ceiling Fixation/ Wall-Mounted/ Suspension Chain by the triangel provided
Easy installation and quick wiring connection to ensure save much labor cost
Emergency kit can be puted inside
Presence Sensor
PG13.5 cable gland>80
2700k-3000k

4000k-4500k

6000k-6500k
600*120*108
CE, EMC,
ROHS, GS,
CB, ENEC, SAA, C-TICK,
UL, CUL
DLC
IK08, IP66

LMF24-60050PCS2290lmLMF24-116050PCS2360lm1160*120*108LMF36-116075PCS3540lmLMF48-1160104PCS4540lmLMF34-156078PCS3030lm1560*120*108LMF48-1560120PCS5150lmLMF70-1560156PCS5600lm




FAQ:

Q1: Can I have a sample order for led light?
A1: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2: What is the lead time?
A2: Samples need 3-5 working days, mass products need 7-10 days.


Q3: Do you have any MOQ limit for led light order?
A3: Low MOQ, 1pc for sample checking is available.

Q4: How do you ship the goods and how long does it take to arrive?
A4: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5: How to proceed an order for led light?
A5: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our
suggestions.Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.

Q6: Is it OK to print my logo on led light product?
A6: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?
A7: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the faulty?
A8: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity.
For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
