24*4W RGBW 4in1 Multi-Color LED Wall Washer Light
Guangzhou MS Lighting Co., Ltd.(China)- Emitting Color:RGB
- Power:96W
- IP Rating:IP65
- Diffuser:Tempered Glass
- Beam Angle:6degree to 120degree
- Lifespan:10000 hours
Base Info
- Model NO.:LED -2007D
- Warranty:2 Years
- Certification:CE, EMC, LVD, RoHS, SGS
- Electric Current Type:AC
- Input Voltage:110V-240V
- DMX Channel:4CH
- Switch Power Supply:Built-in and Auto Switching
- Control Panel:Digital 3 Characters Alphanumeric
- Connector:3-Pinxlr (in and out)
- Electronic Dimmer:1-100% Linear Dimmer
- Electronic Strobe:1-30 Flashes,Second
- Cooling:Entire Casing as Heat Sink (No Fans)
- Flicker Free:Refresh Rate >1000 Hz
- Key Point:Temperature-Protected Easily
- Usage:Theatres, Stage , Robust Housing
- Transport Package:Carton,Flycase
- Specification:L1080*W145*H145 mm
- Trademark:MSLighting
- Origin:Guangzhou, China
- HS Code:94054090
- Production Capacity:500PCS,Week
Description
Specification:Model LED 2007D (24*4W) Housing Material Aluminum Housing Color Black/Silver White Aperture Cover Tempered Glass 5mm Operating voltage 90-130V AC / 176-254V AC Power Switch Power Supply LED current 680mA Control Modes Direct DMX 512, Master/slave. Stand alone DMX Channel 4CH Control panel Digital 3 characters alphanumeric Connector 3-PinXLR (In and Out) NO.of LED 24*4W RGBW 4IN1 LEDS LED Life Time 80000-100,000 hours Beam Angle 25°/30°/45°/60° Power Consumption 96W Light Projecting Distance 10-30M IP Rating Outdoor, IP 65 Operating Temperature -20ºC+45ºC Dimensions L1000*W120*H120 mm Weight 4.80KGS Packing Dimension L1060*W145*H145 mm Gross Weight 5.20KGS Compatibility: 1. Color Range: 16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216) 2. Dimming 0-100%with regulated constant color control 3.Strobe: 10 Flashed per second (any color) 4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable. 5. 4CH DMX Value CH 1 _ Red (1-255, Dimmer, from dart to light) CH 2 _ Green (1-255, Dimmer, from dart to light) CH 3 _ Blue (1-255, Dimmer, from dart to light) CH 3 _ White (1-255, Dimmer, from dart to light) Each Package Included: 1 * LED 2007 LED Wall Washer with
Signal Cable :3-PinXLR DMX In and Out + Water Power cable: Power Cable screw water proof connectors in and out (2ftcable) 1*Power cable: 3 Pin plug and screw water proof connector on other side. (5ft = 1.5m) 1 * User Manual 2* pyrocondensation.cannula (0.66ft = 20cm) 1* Waterproof connector's cover for Power cable
Signal Cable :3-PinXLR DMX In and Out + Water Power cable: Power Cable screw water proof connectors in and out (2ftcable)
