24*4W RGBW 4in1 Multi-Color LED Wall Washer Light
Guangzhou MS Lighting Co., Ltd.(China)- Emitting Color：RGB
- Power：96W
- IP Rating：IP65
- Diffuser：Tempered Glass
- Beam Angle：6degree to 120degree
- Lifespan：10000 hours
Base Info
- Model NO.：LED -2007D
- Warranty：2 Years
- Certification：CE, EMC, LVD, RoHS, SGS
- Electric Current Type：AC
- Input Voltage：110V-240V
- DMX Channel：4CH
- Switch Power Supply：Built-in and Auto Switching
- Control Panel：Digital 3 Characters Alphanumeric
- Connector：3-Pinxlr (in and out)
- Electronic Dimmer：1-100% Linear Dimmer
- Electronic Strobe：1-30 Flashes,Second
- Cooling：Entire Casing as Heat Sink (No Fans)
- Flicker Free：Refresh Rate >1000 Hz
- Key Point：Temperature-Protected Easily
- Usage：Theatres, Stage , Robust Housing
- Transport Package：Carton,Flycase
- Specification：L1080*W145*H145 mm
- Trademark：MSLighting
- Origin：Guangzhou, China
- HS Code：94054090
- Production Capacity：500PCS,Week
Description
Specification:ModelLED 2007D (24*4W)Housing MaterialAluminumHousing ColorBlack/Silver WhiteAperture CoverTempered Glass 5mmOperating voltage90-130V AC / 176-254V ACPower Switch Power SupplyLED current680mAControl ModesDirect DMX 512, Master/slave. Stand aloneDMX Channel4CHControl panelDigital 3 characters alphanumericConnector3-PinXLR (In and Out)NO.of LED24*4W RGBW 4IN1 LEDSLED Life Time80000-100,000 hoursBeam Angle25°/30°/45°/60°Power Consumption96WLight Projecting Distance10-30MIP RatingOutdoor, IP 65Operating Temperature-20ºC+45ºCDimensionsL1000*W120*H120 mmWeight4.80KGSPacking DimensionL1060*W145*H145 mmGross Weight5.20KGSCompatibility:1. Color Range: 16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216)2. Dimming 0-100%with regulated constant color control3.Strobe: 10 Flashed per second (any color)4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable.5. 4CH DMX ValueCH 1 _ Red (1-255, Dimmer, from dart to light)CH 2 _ Green (1-255, Dimmer, from dart to light)CH 3 _ Blue (1-255, Dimmer, from dart to light)CH 3 _ White (1-255, Dimmer, from dart to light)Each Package Included:1 * LED 2007 LED Wall Washer with
Signal Cable :3-PinXLR DMX In and Out + Water Power cable: Power Cable screw water proof connectors in and out (2ftcable)1*Power cable: 3 Pin plug and screw water proof connector on other side. (5ft = 1.5m)1 * User Manual2* pyrocondensation.cannula (0.66ft = 20cm)1* Waterproof connector's cover for Power cable
