Africa Solar Energy Saving Solar Powered Street Lamps

Yangzhou Bright Solar Solutions Co., Ltd.
  • Power Supply：Solar
  • Color Temperature：3000K-5000K
  • Lamp Body Material：Aluminum Alloy
  • Power：9W-120W
  • Application：Square, Highway, Garden
  • IP Rating：IP67

Base Info

  • Model NO.：BR-H15 solar powered street lamps
  • Certification：CCC, CE, CQC, FCC, LVD, RoHS, SASO
  • Input Voltage：12V,24V
  • With Light Source：With Light Source
  • LED Chips Brand：Bridgelux
  • LED Lamp：9W to 120W
  • Solar Street Light Pole：3m-12m Hot Galvanized Pole
  • Solar Battery：100ah-250ah Gel Battery
  • Solar Controller：15A,20A 12V,24V PWM
  • Battery Place：Hang on The Pole
  • Warranty：3 Years, 5 Years
  • Average Life：>8000h, 8000h
  • OEM ODM：Yes
  • IP Level：IP67
  • Pole Height：3m to 12m Street Light Pole
  • Transport Package：Carton & Pallet
  • Specification：9W to 120W solar powered street lamps
  • Trademark：Bright, BR Solar, AS Solar
  • Origin：China
  • HS Code：9405409000
  • Production Capacity：20000PC,Month

Description

Africa Solar Energy Saving Solar Powered Street LampsLED Street Lamp Producing Power 9W-250W
High Lumen:150-150LM/W;Lifespan:50000-100000Hrs* Technical Descriptions* Lamp Body: High-Pressure Die-Casting Aluminum. Corrosion Resistant,IP65 or IP68* Application with Polyester Substance in its Surface.* Reflector: High Purity Aluminum or Stainless Steel SS304,Mirror Polish.* LED Cooler: Aluminum Material, Producing By Module* Cover Glass: High Strength and High Transparent Toughened Glass * Fastener Bolt and Screws: Stainless Steel, Anti-theft screw.* Ambient Temp:-40~+50°C;Humidity:10%~95%* Arm Diameter: 48 or 60mmSolar Panel 18V/36V--Poly &Mono Silicon 5W-310W* Before Production-Control Of  Raw Material Before Use
-Data Recording Of  Raw Material---Products Tracebility* During production-Control At Each Step Of  Production
-Validation Of Each Step By Quality Controllers* After production-Systematic Flash Test On Each PV Modules
-Quality Control With IEC Compliance
-Tests In Our Facility Testing
-Optional: Third Party Inspection Before Shipment If Needing.* Limited Warranty
-Workmanship for 5 years,90% of minimum power output over 12 years,80% over 20 years.
-The Solar Panels Are Manufactured In According To The IEC61215 Standards.Lifespan:20-25 YearsSolar Battery 24AH~250AH/12V* Gelled battery, Sealed Type. Deep Cycle. Maintenance Free.* Real Green Power* Low Internal Resistance* Low Self-discharging Rate* Long-life Design* Wider Temperature Range* Extremely good discharge recovery ability Solar Charge Controller,IP68 Rating* Intellectual Control Technology Based On MCU And Special Software.* Adopt Tandem PWM Charge Control Method, So That The Voltage Loss Of Electrical Circuit Is Only The Half Of  Diode Charge, Charge Efficiency To Improve By 3% - 6%. * The Over Discharging Recovery Control And Automatically Floating Charge Control Can Prolong The Battery Service Life.* Battery Reverse Connection Protection, Over-voltage Protection And Under-voltage Protection.* Solar Module Reverse Connection Protection.* Automatically Recovery Output, Output Over Current Protection And Out Short Circuit Protection* Intelligent Time Control System, It Can Set Up 1-15 Hours Timing Or Delay Time ( Set Period To Resume Current Output, Two Period Can Be Set.)* Light Control, Time Control, Temperature Control* High-precision Voltage Control For The Battery Safety Work.* Waterproof Design.Steel Pole From 3M-12M For Street Lighting. 15M-50M For High Mast Pole* Material
-Q345B/A572,Minimum Yield Strength>=345n/mm2
-Q235B/A36,Minimum Yield Strength>=235n/mm2* Shape
-Round, Multi-pyramidal, Column form, Polygonal Or Conical* Production Process
Raw Material Test→Cutting→Molding Or Bending →Welding (Longitudinal ) →Dimension Verify→Flange Welding→Hole Drilling →Calibration →Debur →Galvanization Or Powder Coating, Painting→Recalibration→Thread→Packaging
Advantage Of Solar Street Lighting Syatem
* Green Energy,Low Power Consumptiom,Save 60%~80% Than Others.
* Higher Power,Higher Brightness Intensity,Good Color Rendition.
* Save Electricity Cost,Save Electric Transformer And Cable Cost,Free Maintanenance.
* Environmental Impact---Eliminate Hazardous Disposal,Low Light Pollution,No Radiation.
* Longer Lifetime: Between 80000-100000 Hrs,If Lighting 12Hrs/Night Could Use At Least 12-22 Years.
* Less Heat Generated Compared To Other Sourses.
* Downward Orientation Of Light Could Adjust Lighting Angles And Lighting Range And Shape On The Ground To      Meet The Road-rectangular,Other Lighting Source Just Could Give Common Round Shape And Small Lighting        Range.

Different Solar Street Light Battery Box Design For ChoosingAfrica Solar Energy Saving Solar Powered Street Lamps
What BR SOLAR Manufacture?

1. Solar Street Lights,All In One Solar Street Lights, All In Two Solar Street Lights, Lithium Solar Street Lights 10W-150W;
2. LED Street Lights, LED Flood Light: 10W-1000W;
3. Solar Power System, Pay As You Go, Solar Lighting System, Solar Water Pump, Solar Panel System, Off And On Grid:5W-200KW;
4. Inverter, Solar Inverter, Inverter With Built-in Controller:300W-200KW;
5. Solar Battery, Gelled Battery, Lithium Battery, LiFePO4 Battery, UPS Battery, OPZV Battety, OPZS Battery: 7AH-3000AH;
6. Solar Panel,Solar Modules Mono And Poly: 5W-500W;
7. Street Light Pole 3-12M,High Mast, Solar High Mast 12-40m;
8. Solar Plaza Lights: 15-35W;
