96*3in1 RGB LED Blinder Light / LED Stage Light
Guangzhou MS Lighting Co., Ltd.(China)- Emitting Color：RGB
- IP Rating：IP 20
- Diffuser：Tempered Glass
- Beam Angle：6-120degree
- Lifespan：50000 hours
- Certification：CE
Base Info
- Model NO.：LED 8E -3in1
- Electric Current Type：AC
- Input Voltage：90-245V
- Color：RGB
- Base Material：Aluminum Alloy
- Transport Package：Carton,Flycase
- Specification：96*48*25CM
- Trademark：MSLighting
- Origin：Guangzhou, China
- HS Code：94054090
- Production Capacity：500PCS,Week
Description
| Specification: | |||
| Model | LED 8E -3in1 RGB | ||
| Operating voltage | 90-130V AC / 176-254V AC | ||
| LED current | 320mA | ||
| NO.of LED | 96*3IN1 RGB LEDS | ||
| Power Consumption | 400W | ||
| Light Projecting Distance | 5-150M | ||
| Housing Material | Aluminum | ||
| Housing Color | Black | ||
| Aperture Cover | Aluminum | ||
| Control Modes | Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization | ||
| DMX Channel | 6CH/3CH | ||
| Control panel | Digital 4 characters alphanumeric | ||
| Connector | 3-PinXLR (In and Out) | ||
| LED Life Time | 80000-100,000 hours | ||
| Beam Angle | 25° ( The other angle would order) | ||
| IP Rating | Indoor | ||
| Operating Temperature | -20ºC -+45ºC | ||
| Compatibility: | |||
| 1. Color Range: 16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216) | |||
| 2. Dimming 0-100%with regulated constant color control | |||
| 3.Strobe: 10 Flashed per second (any color) | |||
| 4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable and Save function. | |||
| 5. 6channel Mode and 3channel Mode would change each other in every light | |||
| 6. 6CH Mode DMX Value | CH 1 _ General dimmer (1-255, Dimmer, from dart to light) | ||
| CH 2_ Red (1-255, Dimmer, from dart to light) | |||
| CH 3 _ Green (1-255, Dimmer, from dart to light) | |||
| CH 4_Blue (1-255, Dimmer, from dart to light) | |||
| CH 5_ Strobe & Color change/ color gradual change open | |||
| CH 6 _Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast) | |||
| 7. 3CH Mode DMX Value | CH 1_ Red (1-255, Dimmer, from dart to light) | ||
| CH 2 _ Green (1-255, Dimmer, from dart to light) | |||
| CH 3_Blue (1-255, Dimmer from dart to light) | |||
| 8. Control Mode | 0: sound activity mode | ||
| 1..DMX control mode | |||
| 2. Adjusting the color manual | |||
| 3. Adjusting the brightness manual | |||
| 4. Adjusting the strobe manual | |||
|
5. Adjusting the strobe speed manual 6. Master-slave control mode, as the master |
|||
| 7. Sound activity synchronization mode | |||
| 8. Adjustingcolor's gradual change manual | |||
| 9.Adjustinggradual change's speed | |||
