• Model NO.：ZGSM-LD27LM
• Certification：CB, CE, EMC, FCC, LVD, RoHS, ISO9001, ISO14001
• Input Voltage：100-240V
• With Light Source：With Light Source
• LED Chips Brand：Lumileds
• Surge Protection：10kv
• Transport Package：Export Cartons
• Specification：495X495X170mm
• Trademark：ZGSM
• Origin：China
• HS Code：9405429000
• Production Capacity：20000PCS,Month

Basic Info.

Model NO. ZGSM-LD27LM Certification CB, CE, EMC, FCC, LVD, RoHS, ISO9001, ISO14001 Input Voltage 100-240V With Light Source With Light Source LED Chips Brand Lumileds Surge Protection 10kv Transport Package Export Cartons Specification 495X495X170mm Trademark ZGSM Origin China HS Code 9405429000 Production Capacity 20000PCS/Month

Product Description

Post Top Mounting LED Street Light with Mutiple Installation Ways
ZGSM L series high power LED street lights are designed for city streets, municipal roadways, bridges, housing projects, public parks, parking lots, yards and gardens, and other settings with needs for high-brightness general illumination during the night time.
All of ZGSM's long life LED luminaires are designed to meet the most demanding specification criteria while offering maximum energy savings, reduced maintenance costs, and a superior quality of light.


Features
1. LED's maintain flux is up to 150 lm/w
2. Significant energy savings
3. Instant on/off
4. Maintenance free
5. Mercury free
6. Superior light quality
7. No UV
8. Simple installation
9. Wide input: 90 - 305V AC, 12V/24VDC
10. Resistant to shock and vibration
11. Temperature compensation technology for long life
12. Copper free aluminum
13. Superior Vision-Care

Electrical Specifications
Lamp's Power: 27W
Operating Voltage: 100-240V AC, 50/60Hz or 12V DC
Optimal Operating Temp: -40 C to +50 C
Power Fact(PF): > 0.95
Power Supply Efficiency: > 90%
Operating Humidity: 10% to 90%

Photometric Specifications
LED Luminous Flux: 4050lm
LED Luminous Efficiency: Up to 150 lm/w
CRI: Ra >= 75
CCT: 3000K, 4000K, 5000K, 5700K

Mechanical Specifications
IP Rating: IP66
IK Rating: IK08
Guarantee: 7 years
Heat Radiator: Anodized Aluminum
Fixture Weight: 7.6kgs
Fixture Dimensions: 480x480x521 mm
Face: Plastic

Packing Information:
Packing Type: 1unit /CTN.
Packing Dimension: 490x490x170 mm
Packing Weight: 9.3kg

FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Samples within 3 days, big order within 1-2 weeks.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3-7 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.1%. Secondly, during the warranty period, we will repair or replace defected products.
