High Lumen LED Street Light 200W Public Lighting

HANGZHOU ZGSM TECHNOLOGY CO., LTD.
  • Color Temperature：4000, 5000 or 5700K
  • Lamp Body Material：Die-Cast Aluminum
  • Power：200W
  • Application：Square, Highway, Garden
  • IP Rating：IP65
  • Certification：CE, LVD, RoHS, Lm-80, ENEC

Base Info

  • Model NO.：ZGSM-LD200KL
  • Input Voltage：100-240,277V AC 50,60Hz
  • Lumen Output：25000 Lm
  • CRI：Minimum 70 CRI
  • Lens：Tempered Glass
  • Packing Type：1 Unit ,CTN
  • Transport Package：Cartons
  • Specification：200W
  • Trademark：ZGSM
  • Origin：China
  • HS Code：94054090
  • Production Capacity：3500PCS,Month

Description

ModelZGSM-LD200KLLED BrandLUMILEDS® LUXEON 3030Driver BrandMeanwell HLG series/ Inventronics/ InventronicsNorminal Wattage200WLED Chip Quantity336pcsInput Voltage100-240/277VACPower Efficiency>90%Power Factor>0.95Lamp Rated Luminous Efficiency>125 lm /wLamp Rated Lumen output25,000 lm (Lumen tolerance +/- 5%)Color Rendering IndexRa>70Color Temperature4000, 5000 or 5700KPhotometric TypeType I Medium;Type II Medium;Type III MediumOptimal Operating Temperature25ºCStorage Temperatures-40°C~50°CWorking EnvironmentBetween-40°C~+50°C, 10%~90%RHTotal Harmonic Distortion< 10%Lumen Maintenance> 75,000 hours -L70, @25 ºC (77 ºF)Body and Shell MaterialsDie-cast aluminum; Tempered GlassIP RatingIP66 with test reportIK RatingIK08 with test reportCertificationCE, ROHS, IOS9001, ISO14001, LM-80Optional Function1-10V DC or PWM Signal or Resistance DimmingTimer/Photocell ControlWarranty7 years Packing DetailsFixture Dimension861 x447 x153 mmFixture Weight12.2 kg /26.9 lbsPacking Dimension915 x495 x225 mmPacking Weight14.7 kg /32.4 lbs
