High Mast Stadium Football Basketball Softball Sport Court LED Flood Light 240W/300W/500W/600W/720W/800W/1000W

Shenzhen ATA Technology Co., Ltd.
  • Color Temperature：Warm White
  • Lamp Body Material：Aluminum
  • Power：500W
  • Projection Distance：>35m
  • Application：Park, Square, Factory, Garden, Parking Lot, Stadium
  • IP Rating：IP65

Base Info

  • Model NO.：ATA-FL500WA
  • Certification：CE, C-tick, EMC, Energy Star, ETL, FCC, GS, LVD, PSE, RoHS, SAA, UL, cUL Dlc
  • Operating Voltage：85-265V
  • Input Voltage：110V
  • LED Chips Brand：Nichia
  • LED Type：SMD3030 with Lm80 Report
  • Luminous Efficiency：150lm,W
  • Colour(CCT)：3000K, 4000K, 5000K, 6000K, RGB
  • Driver Brand：Meanwell Hlg,Meanwell Elg,Sosen
  • Voltage：85-265VAC, 100-277VAC, 90-305V, 180-528V
  • Optional Function：Daylight Sensor
  • Beam Angle：15,25,50,90 Degree
  • Waterproof Grade：IP65
  • Body Colour：Black , Gray
  • Material：Die-Cast Aluminum, Toughened Glass, Silicone Ring
  • Transport Package：Pearl Foam Inner Box and K=K Carton
  • Specification：152*216*40MM
  • Trademark：ATA
  • Origin：Made in China
  • HS Code：9405409000
  • Production Capacity：30, 0000pieces,Month

Description

Item No.Specification
                                                                                                                                                                                                         Power
 Input Voltage
 Lumious Flux(lm)
 Product Dimension
 Luminous Efficiency
      FLH240WX-XXX                240W AC100~277V/347V40800±5% 150LM/W
170LM/W     FLH500WX-XXX              500W AC100~277V/347V85000±5%615.8*542.2*181.8mmFLH720WX-XXX
         720W  AC100~277V/347V122400±5%659.9*853*246.7mm
Applications
Widely used in bars, clubs, hotels, stages, park, sculpture, square, parking lot, playground, shopping mall, plazas, exhibition hall, commercial buildings facade, mosques, museums, art galleries, historical buildings, factories, gymnasiums, stadium, isles, yard, advertising boards, billboards, buildings, lawns, national green lighting projects, building facade and public corridor, stair corridor, garden designs and some other indoor and outdoor places where need spot lighting and light decoration,etc

User Manual:
Switch off power of the mains supply or respectively of the connection lead before doing any works.
Assembly must not damage or destroy conducting paths.
Make sure that the product is mounted on a stable, even and tilt-fixed background.
The complete installation must be done by an electrical expert who is familiar with the valid directives.

Quaity Control:
Stability TEST: make sure 100% of the lamps be aging test at least 48hours
Lighting TEST: make sure 100% of the lamps be lighted before packing
Drop TEST: make sure every single light have been well protected by box
