LED Outdoor Lighting

Home > Product > LED Street Light

25W to 55W Ik08 Outdoor LED Street Lighting with Ce RoHS CB ENEC

HANGZHOU ZGSM TECHNOLOGY CO., LTD.
  • Power Supply：AC
  • Color Temperature：3000K 4000K 5000K 5700K
  • Lamp Body Material：Aluminum Alloy
  • Power：35W
  • Application：Square, Highway, Garden
  • IP Rating：IP66

Base Info

  • Model NO.：ZGSM-LD35KS
  • Certification：CE, EMC, FCC, LVD, RoHS, CB, ENEC, Lm-79, Lm-80
  • Input Voltage：100-240V,277VAC, 12,24VDC
  • With Light Source：With Light Source
  • LED Chips Brand：Lumileds 3030 2D,5050
  • Light Source：LED Light
  • Working Lifetime(Hour)：100, 000 Hours
  • Lens：PC -Primary, Toughened Glass -Secondary
  • Warranty(Year)：7 Years
  • Ik Rating：Ik08
  • Fixture Dimension：614 X224 X135 mm
  • Fixture Weight：6.0 Kg
  • Packing Dimension：855X370 X200 mm
  • Packing Weight：7.5 Kg
  • Transport Package：Export Cartons
  • Specification：ISO9001, ISO14001, CE, ROHS, FCC, CB, ENEC, LM-79
  • Trademark：ZGSM
  • Origin：China
  • HS Code：9405409000
  • Production Capacity：50000 Pieces Per Month

Description

Basic Info.

Model NO. ZGSM-LD35KS Certification CE, EMC, FCC, LVD, RoHS, CB, ENEC, Lm-79, Lm-80 Input Voltage 100-240V/277VAC, 12/24VDC With Light Source With Light Source LED Chips Brand Lumileds 3030 2D/5050 Light Source LED Light Working Lifetime(Hour) 100, 000 Hours Lens PC -Primary, Toughened Glass -Secondary Warranty(Year) 7 Years Ik Rating Ik08 Fixture Dimension 614 X224 X135 mm Fixture Weight 6.0 Kg Packing Dimension 855X370 X200 mm Packing Weight 7.5 Kg Transport Package Export Cartons Specification ISO9001, ISO14001, CE, ROHS, FCC, CB, ENEC, LM-79 Trademark ZGSM Origin China HS Code 9405409000 Production Capacity 50000 Pieces Per Month

Product Description



Series K Toolless Open Street Led Light

  • Wide power range: 25W~200W
25W to 55W Ik08 Outdoor LED Street Lighting with Ce RoHS CB ENEC
Series NoSeries K
Power25W, 35W, 55W, 60W, 90W,120W, 150W, 180W, 200W
Efficacy125-150lm/W
Input Voltage100-240/277 VAC, 50 / 60 Hz
Power Factor>0.95
Surge Protection10KV (Default) / 20KV (available on request)
IP RatingIP66
IK RatingIK08
CCT3000K, 4000K, 5000K, 5700K
CRIRa>70 (Default) / Ra>80
Operating Temperature-40°C to + 50°C
Beam AngleType I, Medium; Type II, Medium; Type III, Medium;
Mounting OptionSide entry or Vertical pole mounted
Warrantys5 Years
CertificationENEC, CE, CB, ROHS, LM79, LM80, LM82, LM84, TM-21, ISTMT, IEC62471/62788
ControlPhotocell, DALI Dimmable, NEMA / Zhaga Socket, Motion Sensor, 1-10V Dimmable, Zigbee or LORA control

25W to 55W Ik08 Outdoor LED Street Lighting with Ce RoHS CB ENEC
