150W LED Liner Flood Light
Wuxi Qiya Lighting and Electric Appliance Factory- Color Temperature：Pure White
- Lamp Body Material：Aluminum
- Power：≥100W
- Projection Distance：>35m
- Application：Park, Square, Factory, Garden
- IP Rating：IP65
Base Info
- Model NO.：QYTGL062-150W
- Certification：CE, RoHS
- Operating Voltage：85-265V
- Input Voltage：24V
- LED Chips Brand：Epistar
- HS Code：94054090
- Production Capacity：10000
Description
Basic Info.
Model NO. QYTGL062-150W Certification CE, RoHS Operating Voltage 85-265V Input Voltage 24V LED Chips Brand Epistar HS Code 94054090 Production Capacity 10000Product Description
Product features- this flood light uses the flip chip technology, no gold wire welding. Avoid the possibility of broken chip .
- High PF isolation power supply.
- Product under current 1800ma, the actual power supply is 1500ma, longer service life.
- The flood light adopts 6063 aluminum for heat dissipation body, lamp bead design elongated, heat conducting efficiency is two times quicker than the traditional die casting aluminum . When it is working temperature difference between the lamp body and chips would not be more than 3 degrees.
- Explosion-proof products resistance to fall off not easily damaged, exempt from violent transport troubles.
- The product is delicate and beautiful.
- Module design ,maintenance-free , and it could be easily extended to high power , like 1000W.
Garden , landscape,advertising board, structure,factory and so on.
Model:QYTG-led097
Power:50W,100W,150W,200W,300W,400W,800W,1000W
Light source: led COB chips
Brand of chips : Epistar
Light effect:≥100lm/W
Voltage:AC 86-265V
Working temperature:-40~55ºC
Protective:IP66
Angle:120°
| Module | Light source | Power | Lumen | Voltage | PF | IP RATE | weight | distance | Size of product(mm) |
| QYTG-led097 | COB inversion | 50W | ≥100lm/W | 86-265V | 95% | IP66 | 1.22kg | 5m | 220*145*80 |
| QYTG-led097 | COB inversion | 100W | ≥100lm/W | 86-265V | 95% | IP66 | 2.45kg | 8m | 220*265*80 |
| QYTG-led097 | COB inversion | 150W | ≥100lm/W | 86-265V | 95% | IP66 | 3.6kg | 12m | 220*400*80 |
| QYTG-led097 | COB inversion | 150W | ≥100lm/W | 86-265V | 95% | IP66 | 3.6kg | 12m | 650*145*80 |
| QYTG-led097 | COB inversion | 200W | ≥100lm/W | 86-265V | 95% | IP66 | 4.84kg | 15m | 435*265*80 |
| QYTG-led097 | COB inversion | 300W | ≥100lm/W | 86-265V | 95% | IP66 | 7.36kg | 25m | 435*400*100 |
| QYTG-led097 | COB inversion | 1000W | ≥100lm/W | 86-265V | 95% | IP66 | 24kg | 80m | 1034*601*80 |
