• Model NO.：6-8-10M-S3 Solar Street System
• Input Voltage：24v
• With Light Source：With Light Source
• LED Chips Brand：Bridgelux
• Lighting Effect：Equal to 350W High Pressure Sodium Lamp
• Designing Points：with Battery Bury Under Ground
• IP Level：IP65, IP68 Against Thief
• LED Lamp Power：15W,24W,30W,42W,60W,70W,80W,100W,120W
• LED Chip Material：CREE, Bridgelux, Epistar
• LED Brightness：120-150lm,W
• Warranty：2 Years, 3 Years, 5 Years
• Transport Package：70PC,40′hq Container
• Specification：80W LED Design Solar Street System
• Trademark：BRIGHT; AS SOLAR; BR SOLAR
• Origin：China
• HS Code：94054090
• Production Capacity：5000PC,Month

Specification for 80W LED Solar Street Lighting SystemPart Name and LifespanTechnical SpecificationSolar Panel:
Lifespan:20-25 years160W*2PC Polycrystalline. High Efficiency. A-class
Adding Aluminum Frame, Tempered Glass.Gelled Battery
Lifespan:5-8 years180Ah/12V*2PC, Gelled battery, Sealed Type.
Deep cycle. Maintenance FreeIntelligent Solar Controller
Lifespan:5-10 years15A/24V,IP65. Automatic Light and Time Control
Over-charging/discharging Protection
Reverse-connection Protection
Switch on Automatically with Light Sensor;
Switch off after designed Hours later.(11-12 Hrs)Light source: High Power LED
Lifespan: More than 50000-100000Hrs80W LED, White Color, Cree Chip, 9600LM,6500K,IP65,High Power, High Brightness. Lamp Housing:
Lifespan: More than 20 yearsDie-casted Aluminum, IP65
High transmittance & Density toughened glass, Battery Box:PVC material, Bury underground, Waterproof and Heat-dissipativeGI Pole System:
Lifespan: More than 20 years
 10M Height, tapered Pole, Steel,
Hot-Dip Galvanized. Plastic Coated, Rust Proof,
With Arm, Bracket, Flange, Fittings, Cable, Etc
Resistant to Wind: ≥150KM/H
