LED Indoor Track Fixtures Luminaires Decorative Rail Modern Living Room Sospeso Office Bar Restaurant Chandelie Rail System

Zhongshan Camilamp Lighting Co., Limited
  • Power Supply：AC
  • Color Temperature：3000K,4000K,5000K
  • Lamp Body Material：Aluminum
  • Power：15W
  • Application：Rail Lighting System
  • IP Rating：IP20

Base Info

  • Model NO.：EC21659
  • Certification：CB, DLC, CCC, CE, CQC, EMC, Energy Star, ETL, FCC, PSE, REACH, RoHS, SAA, UL, VDE
  • Input Voltage：Euro 90-264V,Us 277V
  • With Light Source：With Light Source
  • LED Chips Brand：Osram
  • Transport Package：Variable to Models, See Spec
  • Specification：Variable to models, see spec
  • Trademark：Camilamp,Customized
  • Origin：Guangdong, China
  • Production Capacity：50000

Description

 Product Specification  Watch VideosCooperated Provision  QuotationInstallation Instruction&Tip  ComplaintAgent certification Product Name LED-system  column Rail light Product CodeEC21659 MOQ (PCS)100 Payment TermPayment terms-TT, 30% deposit, 70% balance must be paid before delivery. Irrevocable  L/C at sight. West union, paypal Delivery Time15-20 Days after deposit
★  Product Overview and applicationLED Indoor Track Fixtures Luminaires Decorative Rail Modern Living Room Sospeso Office Bar Restaurant Chandelie Rail SystemLED Indoor Track Fixtures Luminaires Decorative Rail Modern Living Room Sospeso Office Bar Restaurant Chandelie Rail SystemLED Indoor Track Fixtures Luminaires Decorative Rail Modern Living Room Sospeso Office Bar Restaurant Chandelie Rail SystemLED Indoor Track Fixtures Luminaires Decorative Rail Modern Living Room Sospeso Office Bar Restaurant Chandelie Rail System
Areas of application

_ Indoor Meeting Room/Relaxing
_ Bar/Counter/hotel/Hallway
_ Lobby/office

Product family benefits

_ Bright and efficient LED light source that provides superior light quality with wall light CRI >90
_ Low cost operation: - Saves 80% energy compared to other Eliminates the cost of over 6MULTI replacements over the life of the fixture (L70 = 30000 hrs)
_ Aluminium with perfect Finishing
_ Environmental friendly: No hazardous materials
_ UGR ≤ 20
_ SDCM ≤ 5
_ PF ≥ 0.9
_ Flickering ≤ 5%

Product family Features

_ Long lifetime: up to 30,000 h
_  Iron
_ Light Efficiency: up to 70 lm/W
_ Combination of easy and flexible use

Technical data
General Product information
Product NumberEC21659
Product NameLED system column rail light
Brand NameCAMILAMP Lighting
Dim MethodNormal, OR OPTIONAL (DALI, ZIGBEE, BLUETOOTH TUYA, TRIAC PHASE CUT; 0-10V);
THD at Ta≤ 20 (EN61000-3-2)
General Description
 		 LED, IP20,
Watts optional  :12W (Max)
L-N 1KV, L/N-PE 2KV (IEC60598)
IEC 60598Fulfill
Average Rated Life30000 h at normal T
Operating Temperature Range
(90% Lumen output - ambient temperature)		-10°C to 40°C
Operating Temperature Range
(normal and any variations required)		-20°C to 70°C
Quality Guarantee3 Years/5years

Electrical data
Nominal Wattage12W (Max)
Nominal Voltage (Remark US or EU)198-264VAC (EU Standard)/100-277 (US Standard)
Line frequency50/60HZ
IP and IK ingressIP20/IK02
AC input current0.06 A @230Vac
PF factor ≥0.9
IEC 61347Fulfill
Driver BrandOSRAM/3AAA/Eaglerise

Light Technical data
Luminous Flux840 lumens
Light General3000K/4000K/5000K, 90 CRI, 70Lm/W
Light BrandOSRAM/BridgeLux/CREE/Sanan
CCT3000K/4000K/5000K
SCDM≤ 5
UGR≤ 22
Light Flicking ≤ 5%

Key Materials
Housing Material and Installation BoxAluminium
Body Color and Installation Box colorMatt white/Matt black/Matt Rose/Phantom/chrome/bronze/black phantom
Optical Cover Reflector
Cover ColorOpen

Additional product data
Packaging Information
Product number PackagingQuantityOutside dimensions l x w x hGross weight
EC21659 Shipping box (Case)100 See spec
