• Model NO.：LEDARC 4015F
• Exterior Finish：Black
• Power Consumption：420W
• Transport Package：Carton , Flight Case
• Specification：220(D)*559(W)*323.8(H)mm
• Trademark：Color-imagination
• Origin：China
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. LEDARC 4015F Exterior Finish Black Power Consumption 420W Transport Package Carton / Flight Case Specification 220(D)*559(W)*323.8(H)mm Trademark Color-imagination Origin China Production Capacity 50000PCS/Year

Product Description

• Light Source

  Source: 15W 4-IN-1 RGBW LED
  19000lm output
  Flicker free operation
  for broadcast TV and FILM
  Life Span: 50000H
  The life span may vary depending on
  several following factors but not limited to:
  Environmental Conditions, Power/Voltage,
  Usage Patterns (On-Off Cycling), Control,
  and Dimming, etc)



  Optics

  40PCS high efficiency acrylic lens
  8°/25°/45°Lens optional
  10°/30°/45°Field angles



  Colors

  10 Segments controllable individually
  Sophisticated 4 colors RGBW mixed
  Even and soft light
  coverage with pure mixing
  Preset color macros



  Strobe Effect

  0-25Hz high speed shutter/strobe effect
  with variable speed



  Dimming System

  0-100% Smooth linear LED dimming
  Smoother dimming mode available



  Control System

  6/8/40/44 DMX channels USITT DMX-512
  DMX512, master-slave,
  sound activated or auto operation
  3 Sound modes with sensitivity adjustable
  Multi preset internal programs
  DMX recorder and edit function integrated
  Wireless receiver system built-in
  Shielded input signal protection for stable
  signal without interference
  Seetronic IP65 3-Pin
  XLR connectors IN/OUT



  Display System

  2.4" TFT LCD display
  English/Chinese menu
  4 Control buttons
  DMX monitor indicator
  Power status indicator
  Wireless signal indicator
  180°Reversible for LCD display
  Display auto OFF



• Cooling System

  Advanced cooling system integrated
  aluminum and copper with liquid
  Constant temperature readout and
  management function
  Over temperature protection management



  Power Supply

  Electronic supply with active PFC
  AC100-240V 50/60Hz
  Seetronic IP65 PowerCON
  IN/OUT with fuse
  420W Power consumption



  Housing

  Skeleton made of aluminum
  and steel metal plates
  Tilt angle manually adjustable
  1*Polyvent system
  Two side handles on base
  Exterior finish: Black



  Installation

  2*1/4 turn fastening Omega Clamps
  1*Safety attachment point



  Operating Condition

  Operating positions:
  all (device on floor or fixed to a support)
  -25ºC to 45ºC ambient temperature
  IP65 protection rating



  Compliance

  CE
  2014/35/EU - Safety of electrical
  equipment supplied at low voltage (LVD)
  2014/30/EU -
  Electromagnetic Compatibility (EMC)
  2011/65/EU - Restriction of the use of
  certain hazardous substances (RoHS)



  Weight

  N.W.: 12.1kg
  G.W.: 14.5kg



  Dimensions

  Product Dimensions:
  220(D)*559(W)*323.8(H)mm
  Packing Dimensions:
  290(D)*590(W)*400(H)mm
