• Model NO.：PIXARC 7-IP
• Input Voltage：100-240V
• Exterior Finish：Black
• Power Consumption：260W,160W,135W,96W
• Transport Package：Carton , Flight Case
• Specification：76(D)*500(W)*163(H)mm
• Trademark：Color-imagination
• Origin：China
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. PIXARC 7-IP Input Voltage 100-240V Exterior Finish Black Power Consumption 260W/160W/135W/96W Transport Package Carton / Flight Case Specification 76(D)*500(W)*163(H)mm Trademark Color-imagination Origin China Production Capacity 50000PCS/Year

Product Description

• Light Source

  Source:
  W-023A PIXARC 730FIP:
  7*30W 4-IN-1 LEDs, RGBW
  W-023B PIXARC 730TIP:
  7*30W 3-IN-1 LEDs, RGB
  W-023C PIXARC 718SIP:
  7*18W 6-IN-1 LEDs, RGBWA+UV
  W-023D PIXARC 715IP:
  7*15W 5-IN-1 LEDs, RGBWA
  W-023E PIXARC 710FIP:
  7*10W 4-IN-1 LEDs, RGBW
  Each LED controllable individually
  Flicker free operation
  for broadcast TV and FILM
  Life Span: 50000H
  The life span may vary depending on
  several following factors but not limited to:
  Environmental Conditions, Power/Voltage,
  Usage Patterns (On-Off Cycling), Control,
  and Dimming, etc)



  Optics

  High efficiency 40mm PMMA optics
  25° Beam angle (15°/45° optional)
  35°Field angle
  Stunning light output with high intensity



  Colors

  Sophisticated multi colors mixed
  Even and soft light coverage
  with pure mixing
  Preset color macros



  Strobe Effect

  0-25Hz high speed shutter/strobe effect
  with variable speed



  Dimming System

  0-100% Smooth linear LED dimming



  Control System

  2/4/6/28/30(4 colors),
  2/3/5/8/21/23(3 colors),
  6/7/8/12/21/28/35/42/47(6 colors),
  5/6/7/11/35/37/42(5 colors)
  DMX channels USITT DMX-512
  DMX512, master-slave, sound activated or
  auto operation
  Dynamic macro effect with variable speed
  12 Internal color running programs,
  available for strobe effect together
  13 DIY internal color running programs
  with background.foreground colors
  changeable, available for
  strobe effect together
  DMX recorder and edit function integrated
  Shielded input signal protection for stable
  signal without interference
  IP65 3-Pin XLR cables IN/OUT



• Display System

  LED display
  4 Control buttons
  Display auto OFF



  Cooling System

  Advanced cooling system
  integrated aluminum
  Noise free featured



  Power Supply

  Electronic supply with active PFC
  AC100-240V 50/60Hz
  IP65 Power cables IN/OUT
  260W/160W/135W/96W
  Power consumption



  Housing

  Skeleton made of aluminum and steel
  metal plates
  Front window with tempered glass
  2*Polyvent systems
  Tilt angle manually adjustable
  2 Multi-positioning brackets
  Exterior finish: Black



  Installation

  Two hanging points on the brackets
  1*Safety attachment point



  Operating Condition

  Operating positions:
  all (device on floor or fixed to a support)
  -25ºC to 45ºC ambient temperature
  IP65 protection rating



  Compliance

  CE
  2014/35/EU - Safety of electrical
  equipment supplied at low voltage (LVD)
  2014/30/EU -
  Electromagnetic Compatibility (EMC)
  2011/65/EU - Restriction of the use of
  certain hazardous substances (RoHS)



  Weight

  N.W.: 3.8kg
  G.W.: 5.6kg



  Dimensions

  Product Dimensions:
  76(D)*500(W)*163(H)mm
  Packing Dimensions:
  180(D)*710(W)*250(H)mm
