China Supplier 8m Solar LED Street Lighting
BAODE LIGHTING GROUP CO., LTD.- Power Supply:DC
- Lamp Body Material:Aluminum Alloy
- Power:15W-200W
- Application:Square, Highway, Garden
- IP Rating:IP65
- Certification:CCC, CE, FCC, RoHS, SASO, UL
Base Info
- Model NO.:ssl-009
- Input Voltage:12V24V
- With Light Source:With Light Source
- LED Chips Brand:Bridgelux
- LED:Bridelux Chips
- Steel Material:Q235
- Height of The Pole:4m,5m,6m,7m,8m,9m,10m,11m,12m
- Transport Package:Bulk Packing
- Specification:CE ROHS
- Trademark:LUYOU
- Origin:China
- HS Code:940540900
- Production Capacity:1000 Sets,Week
Description
ParametersSolar Module Pmax(W) 30-400W Vmp (V) 35.0V Imp (A) 2.86A Light Fixture Material Aluminum die casting & Toughened glass Operating Temperature -40°C~75°C Protection Level IP65 LED Light Source LED Chip BRIDGELUX / Cree (Top brand in U.S.A.) Color Temperature 3800-6500K(white) Luminous flux 5300 LM Operating temperature -40°C~75°C Current Source DC 12V/24V Power 15W/18W/21W/24W/30W/36W/42W/48W/54W/60W Lighting Pole Height 3m/ 4m/ 5m/ 6m/ 7m/ 8m/ 9m/ 10m/ 11m/ 12 m Material BAOSTEEL GROUP Q235/345/GR60 Surface Treatment Hot-dip galvanizing, Static spray, Size φ60-φ200,δ3-5m, vary according to models Flange Plate 300*300*16, vary according to models Battery Capacity 200AH (100AH*2pcs) Type Gel/AGM Battery Dimension 546*1203*30 Weight 28Kg Controller Rated voltage and current 12V/10A or 24V/10A waterproof Weight 0.165Kg Two times rainy day backup
&Protective Function Two times of rainy day backup.
Good protection: overcharging, discharging, voltage surge, reverse polarity, etc. Accessories Cable 2.5 mm2, 15m Battery Box 200AH ABS battery box or metal box with hot-dip galvanizing spray treatment Foundation Kit Dismountable foundation kit, saving in shipping
Pole 8M High, hot-DIP galvanized steel, powder coated
Light source 45W High power LED, energy saving light, 2000LUMENS, 15LUX on the ground
Solar panel 180W mono-crystalline or poly-crystalline, conversion efficiency 15%
Battery 90AH/12VX2piece, maintenance free, fully-sealed lead acid storage battery
Controller 24V 10A, automatically controlled by microcomputer, over-charge and over-discharge protection
Working time 6-8 hours per day, 3-5 rainy or cloudy days backup when the battery is fully charged
Working temperature -20oC-+50oC
Model of switch light or time control
Wind Resistance 136km/h(please consult with us for the higher wind resistant models)
Battery Position underground, at the foot of the pole
Life span 80000hours
Safety grade IP65
The design, configuration and manufacture according to the customers requirements
Solar panel power 100W-200W
Light power 15W-100W (Luminous Flux 2500-5100LM, Illuminance 15-24Lx)
Pole height 7M -15M
Battery Gel cell deep cycle battery or standard deep cycle battery 80AH 100AH 150AH 200AH
Baode lights ,light up your way
&Protective Function
Good protection: overcharging, discharging, voltage surge, reverse polarity, etc.
Pole 8M High, hot-DIP galvanized steel, powder coated
Light source 45W High power LED, energy saving light, 2000LUMENS, 15LUX on the ground
Solar panel 180W mono-crystalline or poly-crystalline, conversion efficiency 15%
Battery 90AH/12VX2piece, maintenance free, fully-sealed lead acid storage battery
Controller 24V 10A, automatically controlled by microcomputer, over-charge and over-discharge protection
Working time 6-8 hours per day, 3-5 rainy or cloudy days backup when the battery is fully charged
Working temperature -20oC-+50oC
Model of switch light or time control
Wind Resistance 136km/h(please consult with us for the higher wind resistant models)
Battery Position underground, at the foot of the pole
Life span 80000hours
Safety grade IP65
The design, configuration and manufacture according to the customers requirements
Solar panel power 100W-200W
Light power 15W-100W (Luminous Flux 2500-5100LM, Illuminance 15-24Lx)
Pole height 7M -15M
Battery Gel cell deep cycle battery or standard deep cycle battery 80AH 100AH 150AH 200AH
Baode lights ,light up your way
