• Model NO.：LED 3007C
• Warranty：2 Years
• Certification：CE
• Electric Current Type：AC
• Input Voltage：90-245V
• Display：4-LED Display
• Control Mode：DMX 512 ; Autorun and Master,Slave,Sound Active
• Electronic Strobe：1-30 Flashes,Second
• Transport Package：Carton,Flycase
• Specification：Dimension: 56*25*28cm N. G.: 6KGS
• Trademark：MSLighting
• Origin：Guangzhou, China
• HS Code：94054090
• Production Capacity：500PCS,Week

Basic Info.

Model NO. LED 3007C Warranty 2 Years Certification CE Electric Current Type AC Input Voltage 90-245V Display 4-LED Display Control Mode DMX 512 ; Autorun and Master/Slave,Sound Active Electronic Strobe 1-30 Flashes/Second Transport Package Carton/Flycase Specification Dimension: 56*25*28cm N. G.: 6KGS Trademark MSLighting Origin Guangzhou, China HS Code 94054090 Production Capacity 500PCS/Week

Product Description

Item NO : LED-3007C

Light Source:36*18W RGBWA 5IN1 Multi-Color

LED current: 3.0A

Power Consumption: 540W

Light Projecting Distance: 5-100M

Packing Dimension: 12*25*21cm

Gross Weight: 15.00KGS



Specification:

Housing Material: Aluminum

Housing Color: Black/Silver White

Aperture Cover: PMMA

Operating voltage: 90-130V AC / 176-254V AC

Control Mode: Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization

DMX Channel: 9CH/6CH

Control panel: Digital 4 characters alphanumeric

Connector: 3-PinXLR (In and Out)

LED Life Time: 80000-100,000 hours

Beam Angle: 25°/30°/45°/60°

Operating Temperature: -20-+45



Compatibility:

1.  Color Range 16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216)

2. Dimming 0-100%with regulated constant color control

3. Strobe: 30 Flashed per second (any color)

4. Function: it is max mix color, color change, colors gradual change, flash, speed/luminance the adjustable, and save function

5. 8channel Mode and 5channel Mode would change each other in every light

6. 8CH Mode DMX Value

   CH 1 General dimmer   (1-255, from dart to light)

   CH 2 Red              (1-255, Dimmer, from dart to light)

   CH 3 Green           (1-255, Dimmer, from dart to light)

   CH 4 Blue              (1-255, Dimmer, from dart to light)

   CH 5 White             (1-255, Dimmer, from dart to light)

   CH 6 AMBER             (1-255, Dimmer, from dart to light)

   CH 7 Strobe & Color change/ color gradual change open

   CH 8 Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)

7. 5CH Mode DMX Value

    CH 1 Red              (1-255, Dimmer, from dart to light)

    CH 2 Green           (1-255, Dimmer, from dart to light)

    CH 3 Blue              (1-255, Dimmer, from dart to light)

    CH 4 White             (1-255, Dimmer, from dart to light)

    CH 5 AMBER             (1-255, Dimmer, from dart to light)
