• Model NO.：ZGSM-LD200H5
• Certification：CE, EMC, GS, LVD, RoHS, SAA
• Input Voltage：AC 100-240V ,277V,347V,480V, DC 12V ,24V
• With Light Source：With Light Source
• LED Chips Brand：Bridgelux
• Light Source：LED Light
• Working Lifetime(Hour)：100, 000 Hours
• LED Driver：Inventronics
• Color Temperature(CCT)：3000K, 4000K, 5000K, 5700K
• Transport Package：Strengthening Cartons
• Specification：ISO 9001, ISO14001, CE, ROHS, FCC, TUV, SGS, SAA
• Trademark：ZGSM
• Origin：China
• HS Code：94054090
• Production Capacity：20000PCS,Month

Basic Info.

Model NO. ZGSM-LD200H5 Certification CE, EMC, GS, LVD, RoHS, SAA Input Voltage AC 100-240V /277V/347V/480V, DC 12V /24V With Light Source With Light Source LED Chips Brand Bridgelux Light Source LED Light Working Lifetime(Hour) 100, 000 Hours LED Driver Inventronics Color Temperature(CCT) 3000K, 4000K, 5000K, 5700K Transport Package Strengthening Cartons Specification ISO 9001, ISO14001, CE, ROHS, FCC, TUV, SGS, SAA Trademark ZGSM Origin China HS Code 94054090 Production Capacity 20000PCS/Month

Product Description

Series No	Series H
Power	40W, 50W, 60W, 80W, 100W,120W, 150W, 160W, 180W, 200W, 240W, 300W
Efficacy	125-165lm/W
Input Voltage	100-240/277 VAC, 50 / 60 Hz
Power Factor	>0.95
Surge Protection	10KV (Default) / 20KV (available on request)
IP Rating	IP66
IK Rating	IK10
CCT	3000K, 4000K, 5000K, 5700K
CRI	Ra>70 (Default) / Ra>80
Operating Temperature	-40°C to + 50°C
Beam Angle	Type I, Medium; Type II, Medium; Type III, Medium; Type V, Short;
Mounting Option	Side entry or Vertical pole mounted
Warranty	5 Years
Certification	ENEC, CE, CB, ROHS, SAA, UL, LM79, LM80, LM82, LM84, TM-21, ISTMT, IEC62471/62788
Control	Photocell, DALI Dimmable, NEMA /Zhaga Socket, Motion Sensor, Non-Dimmable, 1-10V Dimmable, Zigbee or LORA control
